| General | |
|---|---|
| Weight | 3.9 lb / 1.77 kg (Body Only) |
| Shoe Mount | 1x Cold Shoe |
| Dimensions (W x H x D) | 6.6 x 6 x 5.8" / 16.8 x 15.2 x 14.7 cm |
| Netflix Approved | Yes |
| Packaging Info | |
| Package Weight | 14.445 lb |
| Box Dimensions (LxWxH) | 18.4 x 14.5 x 12.7" |
| Power | |
| Power Consumption | ≤63 W |
| Battery | Canon BP-A Series |
| Imaging | |
| Lens Mount | Canon EF |
| Image Sensor | Full-Frame CMOS |
| Effective Sensor Resolution | Effective: 18.69 Megapixel (5952 x 3140) Actual: 20.8 Megapixel (6062 x 3432) |
| Lens Communication | Yes: with Autofocus Support |
| Image Stabilization | Digital |
| Built-In ND Filter | Mechanical Filter Wheel with 2-Stop (1/4), 4-Stop (1/16), 6-Stop (1/64), 8-Stop (1/256), 10-Stop (1/1024) ND Filters |
| Capture Type | Stills & Video |
| Internal Filter Holder | No |
| Video Capture | |
| Internal Recording | Cinema RAW Light 10/12-Bit 5952 x 3140 from 12 to 59.94 fps 4096 x 2160 from 12 to 59.94 fps 3840 x 2160 from 12 to 59.94 fps XF-AVC 4:2:2 10-Bit 4096 x 2160 from 12 to 59.94 fps (160 to 810 Mb/s) 3840 x 2160 from 12 to 59.94 fps (160 to 810 Mb/s) 1920 x 1080p from 12 to 120 fps (160 to 810 Mb/s) 2048 x 1080 from 12 to 120 fps (160 to 810 Mb/s) XF-AVC 4:2:0 8-Bit 2048 x 1080 from 12 to 120 fps (24 to 35 Mb/s)* *Sensor Crops During Recording |
| Fast-/Slow-Motion Support | Yes |
| Audio Recording | 4-Channel, 24-Bit at 48 kHz via LPCM Audio |
| Gamma Curve | Canon Log 2, Canon Log 3, HDR-HLG, HDR-PQ, Normal 1, Wide DR |
| Built-In Microphone | Mono |
| Exposure Control | |
| Shutter Type | Electronic Rolling Shutter |
| ISO/Gain Sensitivity | Native: 160 to 25,600 (100 to 102,400 Extended) |
| White Balance | Range: 2000 to 15,000K |
| Advertised Dynamic Range | 15 Stops |
| Interface | |
| Media/Memory Card Slot | Single Slot: SD/SDHC/SDXC (UHS-II) Dual Slot: CFexpress Type B |
| Internal Storage | No |
| Video I/O | 1x BNC (12G-SDI) Output 1x BNC (3G-SDI) Output 1x HDMI Output |
| Audio I/O | 2x XLR 3-Pin Mic/Line Input 1x 1/8" / 3.5 mm TRS Stereo Microphone Input 1x 1/8" / 3.5 mm TRS Stereo Microphone Input 1x 1/8" / 3.5 mm TRS Stereo Headphone Output |
| Power I/O | 1x XLR 4-Pin (11.5 to 20VDC) Input |
| Other I/O | 1x BNC (Timecode) Input/Output |
| Wireless | No |
| Mobile App Compatible | No |
| Global Positioning (GPS, GLONASS, etc.) | GPS *Adapter Required |
| Focus | |
| Focus Mode | Automatic, Continuous-Servo AF, Manual Focus |
| Monitor | |
| Display Type | Primary Monitor: Included External 4.3" Touchscreen LCD |
| Viewfinder | |
| Type | Optional, Not Included |
| Others | |
| Marka | Canon |
