| General | |
|---|---|
| Weight | 15.4 lb / 7 kg (Body Only) |
| Materials | Aluminum |
| Mounting | 1x 1/4"-20 Female |
| OS Compatibility | Computer: Windows 10 or Later / macOS 11 Only Mobile: Android/iOS |
| Dimensions (W x H x D) | 12.24 x 8.54 x 8.54" / 31.09 x 21.69 x 21.69 cm 8.54 x 12.24 x 8.54" / 21.69 x 31.09 x 21.69 cm |
| Packaging Info | |
| Package Weight | 22.85 lb |
| Box Dimensions (LxWxH) | 19.4 x 16.5 x 15.3" |
| Environmental | |
| Operating Conditions | 5 to 104°F / -15 to 40°C up to 90% Humidity |
| Power | |
| Power Consumption | PoE: 40 W Power Supply: 12 VDC 40 W |
| Power I/O | 1x Barrel (12VDC) Input |
| PoE Support | Yes: PoE++ 802.3bt |
| Imaging | |
| Image Sensor | 1/2.3"-Type CMOS |
| Effective Sensor Resolution | Effective: 8.29 Megapixel (3840 x 2160) Actual: 21.14 Megapixel |
| Focus Control | Autofocus Manual Focus |
| IR Cut Filter | Yes |
| Video Capture | |
| Internal Recording | No |
| Video Output | 4:2:0 8-Bit via RJ45 3840 x 2160 at 25/6/29.97/12/12.50/15/23.98/5 fps 1920 x 1080p at 15/59.94/23.98/5/25/6/29.97/12/12.50/50 fps 1280 x 720 at 15/59.94/23.98/5/25/6/29.97/12/12.50/50 fps 640 x 360 at 15/59.94/23.98/5/25/6/29.97/12/12.50/50 fps 4:2:2 10-Bit via HDMI 3840 x 2160 at 25/29.97/23.98 fps 1920 x 1080p at 59.94/23.98/25/29.97/50 fps 1920 x 1080i at 59.94/50 fps 1280 x 720 at 59.94/50 fps 4:2:2 10-Bit via SDI/BNC 1920 x 1080p at 25/29.97/50/59.94/23.98 fps 1920 x 1080i at 59.94/50 fps 1280 x 720 at 59.94/50 fps |
| IP Streaming | RTSP/RTP/RTMPS/RTMP/NDI HX 3840 x 2160 at 29.97p, 25p, 23.98p 1920 x 1080 at 29.97p, 25p, 23.98p, 59.94p, 59.94i, 50p, 50i 640 x 360 to 1280 x 720 at 59.94p, 50p |
| Broadcast Output | NTSC/PAL |
| Embedded Audio | SDI |
| Control | |
| Presets | 100 via IP, VISCA |
| Pan/Tilt | Pan: 360° (-180 to 180°) at 0.3 to 60°/s Tilt: 130° (-40 to 215°) at 0.3 to 60°/s |
| Tally Light | Yes |
| Exposure Control | |
| ISO/Gain Sensitivity | Gain: 0 to 36 dB |
| Shutter Speed | 1/2000 to 1/6 Second |
| White Balance | Range: 2000 to 15,000K Presets: AWB, Manual, Set A, Set B |
| Precise Scan Rate Control | No |
| Minimum Illumination | 3 Lux at 1/60 Shutter Speed |
| Flip / Mirror Support | Image Flip |
| Interface | |
| Video I/O | 1x BNC (6G-SDI) Output 1x HDMI Output 1x RJ45 (NDI) Output |
| Other I/O | 1x BNC (Genlock) Input 1x RJ45 (RS-422, VISCA) Control Input |
| Built-In Microphone | Stereo |
| Built-In Speaker | No |
| Lens | |
| Focal Length | 3.7 to 73.4mm (35mm Equivalent: 30.5 to 627mm) |
| Maximum Aperture | f/1.8 to 2.8 |
| Max Optical Zoom | 20x |
| Max Digital Zoom | 20x |
| Field of View | Horizontal: 65.6 to 3.6° Vertical: 39.8 to 2° |
| Minimum Focus Distance | 0.4" / 1 cm (Wide) to 23.6" / 60 cm (Tele) |
| Networking | |
| Wireless | No |
| Others | |
| Marka | Canon |
Price:
912.000,00 ₺
