| Specs | |
|---|---|
| Media/Memory Card Slot | No |
| Dimensions | 10.2 x 7.3 x 3.6" / 25.9 x 18.5 x 9.1 cm |
| Power Requirements | AC/DC Power Adapter (Included) |
| Channels of I/O | Analog:,8 Inputs / 4 Outputs at 192 kHz |
| Maximum Sampling Rate | 192 kHz / 24-Bit |
| Wireless | No |
| Weight | 3.9 lb / 1.8 kg |
| Package Weight | 5.96 lb |
| Display | 6x Multi-Segment LED Meter |
| Host Connection | 1x USB-C (Class-Compliant) |
| Number of Microphone Inputs | 4 |
| Analog Audio I/O | 4x Combo XLR-1/4" TRS Balanced Mic/Line Input,2x 1/4" TRS Balanced Line Input,2x 1/4" TS Unbalanced Hi-Z Input (Front Panel),4x 1/4" TRS Balanced Line Output,2x 1/4" TRS Unbalanced Headphone Output (Front Panel) |
| Maximum Input Level | Mic Inputs:,+14 dBu,Combo XLR-1/4" Line Inputs:,+30 dBu,1/4" Line Inputs:,+17 dBu,Hi-Z Inputs:,+16 dBu |
| Box Dimensions (LxWxH) | 13.5 x 9.3 x 5.8" |
| Frequency Response | Mic Inputs:,20 Hz to 20 kHz ±0.2 dB,Line, Hi-Z Inputs:,20 Hz to 20 kHz ±0.1 dB |
| Network I/O | No |
| Dynamic Range | Hi-Z Inputs:,110 dB (A-Weighted),Mic/Line Inputs:,113 dB (A-Weighted),Headphone Outputs:,111 dB (A-Weighted),Line Outputs:,113 dB (A-Weighted),Monitor Outputs:,112 dB (A-Weighted) |
| Headphone Output Power | 160 mW into 32 Ohms (Max, 1% THD) |
| Digital Audio I/O | No |
| Built-In DSP | No |
| Impedance | Hi-Z Inputs:,1 Megohm (Unbalanced),Headphone Outputs:,32 to 600 Ohms |
| Sample Rates | Up to 192 kHz |
| Host Connection / USB | 1x USB-C (Class-Compliant) |
| THD+N | Mic Inputs:,0.003%,Line/Hi-Z Inputs:,0.001% (1 kHz, at -1 dBFS),Line/Monitor Outputs:,0.002% (1 kHz, at -1 dBFS),Headphone Outputs:,0.002% (1 kHz, at -1 dBFS, 32-Ohm Load) |
| Host Connection Protocol | USB 2.0 |
| Bit Depths | 24-Bit (AD/DA Conversion) |
| Latency | 2.59 ms at 192 kHz (Dependent on Buffer Size, Input to Output),Zero-Latency Direct Monitoring |
| USB (Non-Host) | No |
| Input Level Adjustment | 6x Knob |
| Sync I/O | No |
| MIDI I/O | 1x 1/8" / 3.5 mm TRS Input (DIN 5-Pin Adapter Included),1x 1/8" / 3.5 mm TRS Output (DIN 5-Pin Adapter Included) |
| EIN | Mic Inputs:,-137 dBu A-Weighted,-129 dBu (150-Ohm Source) |
| Sample Rate Conversion | No |
| Built-In Microphone | No |
| Sync Sources | Internal |
| OS Compatibility | macOS 10.8 or Later / Windows 7 or Later |
| Pad | No |
| Gain/Trim Range | Mic Inputs:,62 dB,Line Inputs:,61 dB,Hi-Z Inputs:,59 dB |
| High-Pass Filter | No |
| Solo/Mute | No |
| Phantom Power | 48 V, Selectable On/Off (on 4 Channels) |
| Required Hardware | Available USB 2.0 Port or USB-C Port,USB Cable (Included) |
| Expansion Slots | No |
| Maximum Output Level | Line Outputs:,+17 dBu |
| Mobile Device Compatibility | No |
| AC/DC Power Adapter | 12 VAC at 2 A, Center-Positive (Included) |
| Others | |
| Marka | M-Audio |
