| Specs | |
|---|---|
| Dimensions | 19 x 7 x 1.75" / 48.3 x 17.8 x 4.45 cm |
| Power Requirements | AC/DC Power Adapter (Included) |
| Channels of I/O | Thunderbolt:,26 Input / 26 Output at 44.1/48 kHz |
| Maximum Sampling Rate | 192 kHz / 24-Bit |
| Wireless | No |
| Weight | 6.0 lb / 2.7 kg |
| Package Weight | 8.035 lb |
| Display | No |
| Host Connection | 1x USB-C |
| Number of Microphone Inputs | 8 |
| Analog Audio I/O | 2x Combo XLR-1/4" TS Balanced/Unbalanced Mic/Line/Hi-Z Input,6x Combo XLR-1/4" TRS Balanced Mic/Line Input,2x 1/4" TRS Balanced Line Input,8x 1/4" TRS Balanced Line Output,2x 1/4" TRS Headphone Output,2x 1/4" TRS Insert Output |
| Maximum Input Level | Mic Inputs:,+10 dBu (Balanced, Min Gain),Line Inputs:,+18 dBu (Balanced, Min Gain),Hi-Z Inputs:,+15 dBu (Unbalanced, Min Gain) |
| Box Dimensions (LxWxH) | 24.9 x 10.3 x 3.7" |
| Frequency Response | Mic Inputs:,20 Hz to 20 kHz ±0.15 dB (at 48 kHz, Unity Gain),Line Inputs:,20 Hz to 20 kHz ±0.05 dB (at 48 kHz, Unity Gain),Line Outputs:,20 Hz to 20 kHz ±0.05 dB (at 48 kHz, Unity Gain),Hi-Z Inputs:,20 Hz to 20 kHz ±0.2 dB (at 48 kHz, Unity Gain),Headphone Outputs:,20 Hz to 20 kHz ±0.5 dB (at 48 kHz),Monitor Outputs:,20 Hz to 20 kHz ±0.05 dB (at 48 kHz, Unity Gain) |
| Network I/O | No |
| Dynamic Range | Hi-Z Inputs:,106 dBA,Line Inputs:,118 dBA,Mic Inputs:,110 dBA,Outputs:,118 dBA,Line Outputs:,118 dBA,A/D Converters:,115 dBA,D/A Converters:,115 dBA |
| Headphone Output Power | 175 mW per Channel into 56 Ohms |
| Digital Audio I/O | 2x TOSLINK Optical ADAT Input,2x TOSLINK Optical ADAT Output,1x RCA Coaxial S/PDIF Input,1x RCA Coaxial S/PDIF Output |
| Built-In DSP | No |
| Impedance | Mic Inputs:,1.6 Kilohms,Line Inputs:,10 Kilohms,Line Outputs:,51 Ohms,Hi-Z Inputs:,1 Megohm,Headphone Outputs:,16 to 300 Ohms,Monitor Outputs:,51 Ohms |
| Sample Rates | 44.1 to 192 kHz |
| Host Connection / USB | 1x USB-C |
| Host Connection Protocol | Thunderbolt 3 |
| Bit Depths | 24-Bit |
| Latency | < 1 ms |
| USB (Non-Host) | No |
| Sync I/O | 1x BNC Word Clock Input,1x BNC Word Clock Output |
| MIDI I/O | 1x DIN 5-Pin Input,1x DIN 5-Pin Output |
| Sample Rate Conversion | No |
| Rackmount Size | 1 U (with Included Hardware) |
| Built-In Microphone | No |
| Sync Sources | Word Clock |
| OS Compatibility | macOS 10.11 or Later / Windows 10 or Later |
| Pad | No |
| Gain/Trim Range | Hi-Z Inputs:,60 dB,Mic Inputs:,60 dB |
| RAM Requirements | 4 GB, 8 GB Recommended |
| Storage Requirements | 30 GB |
| Required Hardware | Available Thunderbolt 3 Port |
| Expansion Slots | No |
| Maximum Output Level | Line/Monitor Outputs:,+18 dBu (Balanced) |
| AC/DC Power Adapter | 12 VDC at 5 A (Included) |
| Processor Requirement | Intel Core i5 |
| THD | Hi-Z Inputs:,< 0.005%,Line Inputs:,< 0.005%,Mic Inputs:,< 0.005%,Line Outputs:,< 0.0035%,Headphone Outputs:,< 0.03% |
| Clocking | Internal: |
| Others | |
| Marka | PreSonus |
Price:
37.618,34 ₺
