| Specs | |
|---|---|
| Dimensions | 3.7 x 12 x 12" / 9.4 x 30.4 x 30.4 cm |
| USB I/O | 1x USB-C 2.0 (Host Connection) |
| Number of Analog Input Channels | 8 (4 Mono / 6 Stereo) |
| Wireless | Bluetooth |
| Package Weight | 9.915 lb |
| Analog Output Channels | 1x Stereo Master Output,1x Stereo Control Room/Monitor Output,1x Mono Bus/Subgroup Output,1x Mono FX Send Output,1x Stereo Headphone Output |
| Number of Mic Preamps | 4 |
| Box Dimensions (LxWxH) | 15.6 x 14.5 x 7.6" |
| Frequency Response | Headphone Output:,20 Hz to 20 kHz +0.5/-1.5 dB,Output:,20 Hz to 20 kHz +0.5/-1.5 dB,Mic Input to Analog Output:,20 Hz to 20 kHz +0.5/-1.5 dB,Line Input to Analog Output:,20 Hz to 20 kHz +0.5/-1.5 dB,Hi-Z Input to Analog Output:,20 Hz to 20 kHz +0.5/-1.5 dB,Mic Input to USB:,20 Hz to 40 kHz +0.5/-1.5 dB,Line Input to USB:,10 Hz to 40 kHz +0.5/-1.5 dB,Hi-Z Input to USB:,20 Hz to 40 kHz +0.5/-1.5 dB |
| Rack Mountable | No |
| Headphone Output Power | 150 mW per Channel into 60 Ohms |
| Max I/O Capacity | 8x Input / 4x Output |
| Built-In Effects | Yes |
| EQ | 3-Band EQ |
| Sample Rates | AD/DA Conversion:,44.1 / 48 / 88.2 / 96 kHz,Stereo Record:,44.1 kHz |
| Mix Routing | 1x Main Mix,1x FX Send,Aux Bus/Subgroup |
| AC Input Power | 100 to 240 VAC, 50 / 60 Hz |
| THD+N | Headphone Output:,< 0.01% (-1 dBFS, Unweighted),Hi-Z Input:,< 0.01% (-1 dBFS, A-Weighted, 1 kHz),< 0.01% (-1 dBFS, Unweighted, 1 kHz),Line Input:,< 0.01% (-1 dBFS, A-Weighted, 1 kHz),Mic Input:,< 0.01% at Min Gain (A-Weighted),Output:,< 0.01% (-1 dBFS, Unweighted) |
| Analog Inputs | 1/4" TRS Balanced Line Input,1/4" TS Unbalanced Hi-Z Input,XLR 3-Pin Mic Input |
| Max Multitrack Recording | 8 Tracks |
| OS Compatibility | macOS 10.11 or Later / Windows 7 or Later |
| Gain/Trim Range | 1/4" Hi-Z Input:,50 dB,1/4" Line Input:,-20 dB to +30 dB,1/4" Stereo Line Input:,-15 dB to +25 dB,Line/Mic Input:,0 dB to +50 dB,Stereo Input:,+5 dB to +45 dB |
| EQ Parameters | High: ±15 dB at 12 kHz (Shelving),Mid: ±15 dB at 2.5 kHz, 0.55 Q (Notch/Peak),Low: ±15 dB at 80 Hz (Shelving) |
| Filters | High-Pass: 100 Hz, 18 dB/Octave |
| Phantom Power | +48 V (Applied to All Inputs) |
| RAM Requirements | 4 GB, 8 GB Recommended |
| Bit Depth | 24-Bit |
| SNR | Line Input to Analog Output:,94 dB (+4 dBu Reference),Mic Input to Output:,94 dB (+4 dBu Reference) |
| Max Input Level | Mic Input:,+22 dBu at Unity Gain (±1.0 dB, 1 kHz at 0.5% THD+N),1/4" TRS Line Input:,+22 dBu at Min Gain (±1.0 dB, 1 kHz at 0.5% THD+N),Hi-Z Input:,+22 dBu at Min Gain (±1.0 dB, 1 kHz at 0.5% THD+N) |
| Analog Dynamic Range | Headphone Output:,> 103 dBA,Output:,> 105 dB at Min Gain,> 100 dB at Mid Gain,Hi-Z Input:,> 108 dBA |
| I/O Impedance | 1/4" TRS Input:,10 Kilohms (Balanced),1/4" TS Hi-Z Input:,> 1 Megohm,Mic Input:,1 Kilohms,Output:,100 Ohms (Balanced) |
| Analog Outputs | 1/4" TRS Headphone Output,XLR 3-Pin Balanced Main Output,1/4" TRS Balanced Control Room Output,1/4" TRS Balanced Monitor Output,1/4" TRS Balanced FX Output |
| Media Support | SD, SDHC |
| Max Media Storage Capacity | SD: 2 GB,SDHC: 32 GB |
| File Format Support | Record: WAV,Playback: MP3, WAV |
| Others | |
| Marka | PreSonus |
