| Specs | |
|---|---|
| Media/Memory Card Slot | No |
| Dimensions | 7.1 x 4.8 x 1.8" / 18.03 x 12.19 x 4.57 cm |
| Power Requirements | Thunderbolt Bus Power |
| Channels of I/O | Analog:,2 Inputs / 4 Outputs at 192 kHz |
| Maximum Sampling Rate | 192 kHz / 24-Bit |
| Wireless | No |
| Weight | 1.4 lb / 0.6 kg |
| Package Weight | 2.79 lb |
| Display | 5x Multi-Segment LED Meter |
| Host Connection | 1x USB-C |
| Number of Microphone Inputs | 2 |
| Analog Audio I/O | 2x Combo XLR-1/4" TRS Balanced Mic/Line Input,1x 1/4" TS Unbalanced Hi-Z Input (Front Panel),1x 1/4" TRS Unbalanced Headphone Output (Front Panel),2x 1/4" TRS Balanced Monitor Output |
| Maximum Input Level | Mic Inputs:,+25.2 dBu (Min Gain, with Pad),Line Inputs:,+20.7 dBu,Hi-Z Inputs:,+12.5 dBu (Min Gain) |
| Box Dimensions (LxWxH) | 8.5 x 6.4 x 4.6" |
| Frequency Response | System:,20 Hz to 20 kHz ±0.1 dB |
| Network I/O | No |
| Dynamic Range | Mic/Line/Hi-Z Inputs:,118 dBA,Headphone Outputs:,115 dBA (600-Ohm Load),Monitor Outputs:,115 dBA |
| Headphone Output Power | 240 mW into 32 Ohms,62 mW into 300 Ohms |
| Digital Audio I/O | No |
| Built-In DSP | Yes |
| Impedance | Mic Inputs:,5.5 Kilohms,Line Inputs:,10 Kilohms,Hi-Z Inputs:,1 Megohm,Monitor Outputs:,100 Ohms |
| Sample Rates | Up to 192 kHz |
| Host Connection / USB | 1x USB-C |
| Operating Conditions | 32 to 95°F / 0 to 35°C at 20 to 80% Humidity |
| THD+N | Mic Inputs:,-108 dBFS,Line Inputs:,-107 dBFS,Hi-Z Inputs:,-105 dBFS,Monitor Outputs:,-106 dBFS,Headphone Outputs:,-97 dB (600-Ohm Load),-88 dB (32-Ohm Load) |
| Host Connection Protocol | Thunderbolt 3 |
| Bit Depths | 24-Bit |
| Latency | 1.1 ms at 96 kHz (Input to Output) |
| USB (Non-Host) | No |
| Input Level Adjustment | 1x Knob |
| Power Consumption | 10 W |
| Sync I/O | No |
| Storage Conditions | -40 to 176°F / -40 to 80°C |
| MIDI I/O | No |
| Sample Rate Conversion | No |
| Built-In Microphone | No |
| Sync Sources | Internal |
| OS Compatibility | macOS 10.14 to 12 / Windows 10 or Later |
| Pad | Mic:,-20 dB (Switchable per Channel) |
| Gain/Trim Range | Mic/Line/Hi-Z Inputs:,+10 dB to +65 dB |
| High-Pass Filter | 75 Hz, 12 dB/Octave |
| Solo/Mute | No |
| Phantom Power | 48 V, Selectable On/Off (Selectable on Individual Inputs) |
| Storage Requirements | 10 GB |
| Required Hardware | Available Thunderbolt 3 Port,Thunderbolt 3 Cable |
| Expansion Slots | No |
| Maximum Output Level | Monitor Outputs:,+20.7 dBu |
| Mobile Device Compatibility | No |
| Processor Requirement | Intel Core i7 |
| Others | |
| Marka | Universal Audio |
