| Specs | |
|---|---|
| Media/Memory Card Slot | No |
| Dimensions | 6.31 x 5.86 x 2.6" / 16.03 x 14.88 x 6.6 cm (Chassis Only),6.31 x 6.2 x 2.6" / 16.03 x 15.7 x 6.6 cm (Including Controls and Protrusions) |
| Power Requirements | AC/DC Power Adapter (Included) |
| Channels of I/O | Analog:,2 Inputs / 6 Outputs at 192 kHz,Digital:,8 Inputs / 0 Outputs at 48 kHz,4 Inputs / 0 Outputs at 96 kHz,2 Inputs / 0 Outputs at 192 kHz |
| Maximum Sampling Rate | 192 kHz / 24-Bit |
| Wireless | No |
| Weight | 2.4 lb / 1.1 kg |
| Package Weight | 4.11 lb |
| Display | 5x Multi-Segment LED Meter |
| Host Connection | 1x USB-B |
| Number of Microphone Inputs | 2 |
| Analog Audio I/O | 2x Combo XLR-1/4" TRS Balanced/Unbalanced Mic/Line Input,1x 1/4" TS Unbalanced Hi-Z Input (Front Panel),2x 1/4" TRS Balanced/Unbalanced Line Output,1x 1/4" TRS Unbalanced Headphone Output,2x 1/4" TRS Balanced/Unbalanced Monitor Output |
| Maximum Input Level | Mic Inputs:,+26 dBu (Min Gain, with Pad),Line Inputs:,+20.2 dBu,Hi-Z Inputs:,+12 dBu |
| Box Dimensions (LxWxH) | 7.9 x 7.8 x 5.5" |
| Frequency Response | Mic, Line, Hi-Z Inputs:,20 Hz to 20 kHz ±0.1 dB,Line, Headphone, Monitor Outputs:,20 Hz to 20 kHz ±0.1 dB |
| Network I/O | No |
| Dynamic Range | Hi-Z Inputs:,117 dBA,Line Inputs:,117.5 dBA,Mic Inputs:,118 dBA,Headphone Outputs:,113 dBA,Line Outputs:,118 dBA,Monitor Outputs:,115 dBA |
| Headphone Output Power | 80 mW into 600 Ohms (Max) |
| Digital Audio I/O | 1x TOSLINK Optical ADAT / S/PDIF Input (S/MUX4 Support) |
| Built-In DSP | Yes |
| Impedance | Mic Inputs:,5.4 Kilohms,Line Inputs:,10 Kilohms,Line/Monitor Outputs:,600 Ohms,Hi-Z Inputs:,1 Megohm |
| Sample Rates | Up to 192 kHz |
| Host Connection / USB | 1x USB-B |
| Operating Conditions | 32 to 95°F / 0 to 35°C at 20 to 80% Humidity |
| AC Input Power | 100 to 240 VAC, 50 / 60 Hz |
| THD+N | Mic Inputs:,-110 dBFS,Line Inputs:,-108 dBFS,Hi-Z Inputs:,-101 dBFS,Monitor Outputs:,-105 dBFS,Line Outputs:,-107 dBFS,Headphone Outputs:,-101 dBFS |
| Host Connection Protocol | USB 3.0 / 3.1/3.2 Gen 1 |
| Bit Depths | 24-Bit (AD/DA Conversion) |
| Latency | 1.1 ms at 96 kHz (Input to Output) |
| USB (Non-Host) | No |
| Input Level Adjustment | 1x Knob |
| Power Consumption | 12 W (Maximum) |
| Sync I/O | No |
| Storage Conditions | -40 to 176°F / -40 to 80°C |
| MIDI I/O | No |
| EIN | Mic Inputs:,-127 dBu |
| Sample Rate Conversion | No |
| Built-In Microphone | No |
| Sync Sources | ADAT, Internal, S/PDIF |
| OS Compatibility | Windows 7 or Later |
| Pad | -20 dB (Switchable per Channel) |
| Gain/Trim Range | Mic/Line/Hi-Z Inputs:,+10 to +65 dB |
| High-Pass Filter | 75 Hz |
| Solo/Mute | No |
| Phantom Power | 48 V, Selectable On/Off (Selectable on Individual Inputs) |
| SNR | Mic Inputs:,118 dBA,Line Inputs:,117.5 dBA,Hi-Z Inputs:,117 dBA,Line Outputs:,118 dBA,Headphone Outputs:,113 dBA,Monitor Outputs:,115 dBA |
| Storage Requirements | 6 GB |
| Required Hardware | Available USB 3.0 / 3.1/3.2 Gen 1 Port,USB Cable (Included) |
| Expansion Slots | No |
| Maximum Output Level | Line/Monitor Outputs:,+20.2 dBu |
| Mobile Device Compatibility | No |
| AC/DC Power Adapter | 12 VDC, Center-Positive (Included) |
| Processor Requirement | Intel Core i3 |
| Others | |
| Marka | Universal Audio |
