| Specs | |
|---|---|
| Media/Memory Card Slot | No |
| Dimensions | 19 x 13.5 x 1.74" / 48.3 x 34.3 x 4.42 cm (Including Controls and Protrusions) |
| Power Requirements | AC/DC Power Adapter (Included) |
| Channels of I/O | Analog:,18 Inputs / 20 Outputs at 192 kHz,Digital:,2 Inputs / 2 Outputs at 192 kHz,Dante:,16 Inputs / 16 Outputs |
| Maximum Sampling Rate | 192 kHz / 24-Bit |
| Wireless | No |
| Weight | 8.0 lb / 3.6 kg |
| Package Weight | 15.99 lb |
| Display | 18x Multi-Segment LED Meter |
| Host Connection | 2x USB-C |
| Number of Microphone Inputs | No |
| Analog Audio I/O | 2x XLR 3-Pin Balanced Monitor Output |
| Box Dimensions (LxWxH) | 23.3 x 17.1 x 7.8" |
| Frequency Response | Monitor Outputs:,20 Hz to 20 kHz ±0.02 dB |
| Network I/O | 2x RJ45 AES67 / Dante (Gigabit) |
| Dynamic Range | Monitor Outputs:,133 dBA |
| Digital Audio I/O | 1x XLR 3-Pin AES3 Input,1x XLR 3-Pin AES3 Output |
| Built-In DSP | Yes |
| Impedance | Monitor Outputs:,100 Ohms,Word Clock :,75 Ohms |
| Sample Rates | 44.1 to 192 kHz |
| Host Connection / USB | 2x USB-C |
| Operating Conditions | 32 to 104°F / 0 to 40°C |
| AC Input Power | 100 to 240 VAC, 50 / 60 Hz |
| THD+N | Monitor Outputs:,-129 dB / 0.000037% (1 kHz, at -1 dBFS) |
| Host Connection Protocol | Thunderbolt 3 |
| Bit Depths | 24-Bit |
| Latency | 1 ms at 96 kHz (Over Thunderbolt) |
| USB (Non-Host) | No |
| Power Consumption | 30 W (Typical),72 W (Maximum) |
| Sync I/O | 1x BNC Word Clock Input,1x BNC Word Clock Output |
| MIDI I/O | No |
| Sample Rate Conversion | No |
| Rackmount Size | 1 U |
| Built-In Microphone | (Talkback) |
| Sync Sources | AES3, Dante, Internal, Word Clock |
| OS Compatibility | macOS 10.15 to 14 / Windows 10 or Later |
| Pad | No |
| High-Pass Filter | No |
| Solo/Mute | Mute per Master |
| Phantom Power | No |
| Storage Requirements | 25 GB (100 GB Recommended) |
| Required Hardware | Thunderbolt 3 Cable |
| Expansion Slots | No |
| Maximum Output Level | Monitor Outputs:,+24 dBu (+4 dBu),+10 dBV (-10 dBV) |
| Mobile Device Compatibility | No |
| AC/DC Power Adapter | 12 VDC at 6 A (Included) |
| Clocking | Word Clock:,Input Termination: 75 Ohms (Switchable),Lock Range: 44.1 to 192 kHz ±4% of Sample Rate |
| Others | |
| Marka | Universal Audio |
Price:
265.048,92 ₺
