| Specs | |
|---|---|
| Media/Memory Card Slot | No |
| Dimensions | 6.31 x 6.2 x 2.6" / 16.03 x 15.7 x 6.6 cm |
| Power Requirements | AC/DC Power Adapter (Included) |
| Channels of I/O | Analog:,2 Inputs / 4 Outputs at 192 kHz,ADAT:,8 Inputs / 0 Outputs at 44.1/48 kHz,4 Inputs / 0 Outputs at 88.2/96 kHz,2 Inputs / 0 Outputs at 176.4/192 kHz,S/PDIF:,2 Inputs / 0 Output at 44.1/48/88.2/96 kHz |
| Maximum Sampling Rate | 192 kHz / 24-Bit |
| Wireless | No |
| Weight | 2.2 lb / 1.0 kg (without Accessories) |
| Package Weight | 4.255 lb |
| Display | 5x Multi-Segment LED Meter |
| Host Connection | 1x USB-C |
| Number of Microphone Inputs | 2 |
| Analog Audio I/O | 2x Combo XLR-1/4" TRS Balanced/Unbalanced Mic/Line Input,1x 1/4" TS Unbalanced Hi-Z Input (Front Panel),2x 1/4" TRS Balanced/Unbalanced Line Output,1x 1/4" TRS Unbalanced Headphone Output,2x 1/4" TRS Balanced/Unbalanced Monitor Output |
| Maximum Input Level | Mic Inputs:,25.6 dBu (with Pad),Line Inputs:,20.2 dBu (Min Gain),Hi-Z Inputs:,12.2 dBu (Min Gain) |
| Box Dimensions (LxWxH) | 8.4 x 7.7 x 5.5" |
| Frequency Response | Mic, Line, Hi-Z Inputs:,20 Hz to 20 kHz ±0.05 dB,Line Outputs:,20 Hz to 20 kHz ±0.05 dB,Headphone, Monitor Outputs:,20 Hz to 20 kHz ±0.1 dB |
| Network I/O | No |
| Dynamic Range | Hi-Z Inputs:,121 dBA (A-Weighted),Line Inputs:,122 dBA (A-Weighted),Mic Inputs:,123 dBA (A-Weighted),Headphone Outputs:,124 dBA (A-Weighted),Line Outputs:,126 dBA (A-Weighted),Monitor Outputs:,127 dBA (A-Weighted) |
| Headphone Output Power | 96 mW into 300 Ohms (Max) |
| Digital Audio I/O | 1x TOSLINK Optical ADAT / S/PDIF Input (S/MUX4 Support) |
| Built-In DSP | Yes |
| Impedance | Mic Inputs:,5.4 Kilohms,Line Inputs:,10 Kilohms,Line Outputs:,100 Ohms,Hi-Z Inputs:,1 Megohm,Monitor Outputs:,100 Ohms |
| Sample Rates | 44.1 to 192 kHz |
| Host Connection / USB | 1x USB-C |
| Operating Conditions | 32 to 104°F / 0 to 40°C |
| AC Input Power | 100 to 240 VAC, 50 / 60 Hz |
| THD+N | Mic Inputs:,-115 dB (1 kHz, at -1 dBFS),Hi-Z Inputs:,-108 dB (1 kHz, at -1 dBFS),Line Inputs:,-114 dB (1 kHz, at -1 dBFS),Line Outputs:,-117 dB (1 kHz, at -1 dBFS),Monitor Outputs:,-117 dB,Headphone Outputs:,-98 dB (1 kHz, at -1 dBFS) |
| Host Connection Protocol | Thunderbolt 3, USB 3.1/3.2 Gen 2 |
| Bit Depths | 24-Bit (AD/DA Conversion) |
| Latency | 1.1 ms at 96 kHz (Input to Output) |
| USB (Non-Host) | No |
| Input Level Adjustment | 1x Knob |
| Power Consumption | 15 W (Maximum) |
| Sync I/O | No |
| MIDI I/O | No |
| Sample Rate Conversion | No |
| Built-In Microphone | Yes |
| Sync Sources | ADAT, Internal, S/PDIF |
| OS Compatibility | Windows 10 or Later / macOS |
| Pad | Mic:,-20 dB (Switchable per Channel) |
| Gain/Trim Range | Mic/Line/Hi-Z Inputs:,+10 dB to +65 dB |
| High-Pass Filter | 75 Hz |
| Solo/Mute | Mute per Master |
| Phantom Power | 48 V, Selectable On/Off (Selectable on Individual Inputs) |
| Storage Requirements | 10 GB |
| Required Hardware | Thunderbolt Port,USB Cable (Not Included) |
| Expansion Slots | No |
| Maximum Output Level | Line/Monitor Outputs:,20.2 dBu |
| Mobile Device Compatibility | No |
| AC/DC Power Adapter | 12 VDC, Center-Positive (Included) |
| Processor Requirement | PC:,Intel Core i7 or Better (64-Bit, Recommended),Intel Xeon,AMD |
| Others | |
| Marka | Universal Audio |
