| Specs | |
|---|---|
| Media/Memory Card Slot | No |
| Dimensions | 19 x 12 x 1.74" / 48.3 x 30.5 x 4.42 cm (Chassis Only),19 x 13.5 x 1.74" / 48.3 x 34.3 x 4.42 cm (Including Controls and Protrusions) |
| Power Requirements | AC/DC Power Adapter (Included) |
| Channels of I/O | 18 Inputs / 24 Outputs |
| Maximum Sampling Rate | 192 kHz / 24-Bit |
| Wireless | No |
| Weight | 8.8 lb / 4.0 kg |
| Package Weight | 16.855 lb |
| Display | 10x Color Multi-Segment LED Meter |
| Host Connection | 1x USB-C |
| Number of Microphone Inputs | 4 |
| Analog Audio I/O | 4x Combo XLR-1/4" TRS Balanced/Unbalanced Mic/Line Input,8x 1/4" TRS Balanced Line Input,2x 1/4" TS Unbalanced Hi-Z Input,8x 1/4" TRS Unbalanced Line Output,2x 1/4" TRS Balanced Monitor Output |
| Maximum Input Level | Mic Inputs:,26 dBu (Pad On),Line Inputs:,24 dBu (Reference Level at +4 dBu),Hi-Z Inputs:,12.6 dBu (at Minimum Gain) |
| Box Dimensions (LxWxH) | 23.6 x 17.3 x 7.9" |
| Frequency Response | Mic, Line Inputs:,20 Hz to 20 kHz ±0.07 dB,Line Outputs:,20 Hz to 20 kHz ±0.05 dB,Hi-Z Inputs:,20 Hz to 20 kHz ±0.08 dB,Headphone Outputs:,20 Hz to 20 kHz ±0.02 dB,Monitor Outputs:,20 Hz to 20 kHz ±0.02 dB |
| Network I/O | No |
| Dynamic Range | Hi-Z Inputs:,122 dBA,Line Inputs:,124 dBA,Mic Inputs:,123 dBA,Headphone Outputs:,126 dBA,Line Outputs:,127 dBA,Monitor Outputs:,130 dBA |
| Headphone Output Power | 120 mW into 300 Ohms,67 mW into 600 Ohms |
| Digital Audio I/O | 2x Mini-TOSLINK / 3.5 mm Optical ADAT Input (S/MUX Support),2x Mini-TOSLINK / 3.5 mm Optical ADAT Output (S/MUX Support),1x RCA Coaxial S/PDIF Input,1x RCA Coaxial S/PDIF Output |
| Built-In DSP | Yes |
| Impedance | Mic Inputs:,5.4 Kilohms,Line Inputs:,10 Kilohms,Line Outputs:,100 Ohms,Hi-Z Inputs:,1 Megohm,Monitor Outputs:,100 Ohms,Word Clock Inputs:,75 Ohms |
| Sample Rates | Up to 192 kHz |
| Host Connection / USB | 1x USB-C |
| Operating Conditions | 32 to 104°F / 0 to 40°C |
| AC Input Power | 100 to 240 VAC, 50 / 60 Hz |
| THD+N | Mic Inputs:,-115 dB / 0.00018%,Hi-Z Inputs:,-111 dB / 0.00028%,Line Inputs:,-116 dB / 0.00016%,Line Outputs:,-119 dB / 0.00011%,Monitor Outputs:,-127 dB / 0.000045%,Headphone Outputs:,-117 dB / 0.00014%,-118 dB / 0.00013% |
| Host Connection Protocol | Thunderbolt 3 |
| Bit Depths | 24-Bit |
| Latency | 1.1 ms at 96 kHz |
| USB (Non-Host) | 1x USB-C (Device Connection) |
| Input Level Adjustment | 1x Knob |
| Power Consumption | 72 W,30 W (Typical) |
| Sync I/O | 1x BNC Word Clock Input,1x BNC Word Clock Output |
| MIDI I/O | No |
| Sample Rate Conversion | No |
| Rackmount Size | 1 U (with Included Hardware) |
| Built-In Microphone | (Talkback) |
| Sync Sources | ADAT, Internal, S/PDIF, Word Clock |
| OS Compatibility | Windows / macOS |
| Pad | Mic:,-20 dB (Switchable per Channel) |
| Gain/Trim Range | Mic/Line/Hi-Z Inputs:,+10 dB to +65 dB |
| Solo/Mute | Mute per Master |
| Phantom Power | 48 V, Selectable On/Off |
| Expansion Slots | No |
| Maximum Output Level | Line Outputs:,24 dBu (Reference Level at +4 dBu),12.2 dBu (Reference Level at -10 dBv),Headphone Outputs:,17.8 dBu (300 Ohms Load, 1 kHz at 16.8 dBu, -1 dBFS),18.3 dBu (600 Ohms Load, 1 kHz at 17.3 dBu, -1 dBFS)),Monitor Outputs:,24 dBu (Reference Level at +4 dBu),12.2 dBV (Reference Level at -10 dBv) |
| Mobile Device Compatibility | No |
| AC/DC Power Adapter | 12 VDC at 6 A |
| Others | |
| Marka | Universal Audio |
Price:
200.392,87 ₺
