| General | |
|---|---|
| Certifications | C-Tick, CE, FCC |
| Dimensions | 3.7" / 9.4 cm |
| Weight | 5.64 oz / 160 g |
| Packaging Info | |
| Package Weight | 0.54 lb |
| Box Dimensions (LxWxH) | 5.65 x 5.55 x 1.2" |
| Environmental | |
| Operating Temperature | 41 to 104°F / 5 to 40°C |
| Operating Humidity | 0 to 90% |
| Storage Temperature | -4 to 113°F / -20 to 45°C |
| Power | |
| Power Consumption | 10 W |
| Inputs/Outputs | |
| System Connection | PCIe 2.0 x4 |
| Other I/O | 1x BNC Blackburst, Reference, Tri-Level Sync Input |
| Audio Inputs | No |
| Simultaneous Multi-Input Support | Not Specified by Manufacturer |
| Inputs/Outputs | 4x BNC (3G-SDI) |
| Format Support | |
| Embedded Audio | SDI: 16-Channel |
| Input Video Format | SDI (8/10/12-Bit 4:4:4/4:2:2 RGB, YUV) 1080p at 23.98/24/25/29.97/30/50/59.94/60 fps 1080PsF at 23.98/24/25/29.97/30 fps 1080i at 50/59.94/60 fps 720p at 50/59.94/60 fps 576i / 625 lines at 50 fps 480i / 525 lines at 60 fps |
| Standards | |
| HDR Support | Not Specified by Manufacturer |
| Video Standard Compliance | SMPTE 259M/292M/296M/372M/425M ITU -R BT.601/BT.656 |
| Hardware | |
| OS Compatibility | Windows 8.1.10 or Later macOS 10.14.15 or Later Linux |
| Others | |
| Marka | Blackmagic Design |
