| General | |
|---|---|
| Certifications | FCC, CE, and C-Tick |
| Weight | 3.1 oz / 87 g |
| Length | 3.9" / 9.9 cm, Low-Profile Form Factor |
| Operating Temperature | 41 to 104°F / 5 to 40°C |
| Inputs/Outputs | 4 x Mini BNC 3G-SDI (Bidirectional, 12-Bit SD/HD) 1 x Reference In |
| Storage Temperature | -4 to 113°F / -20 to 45°C |
| Power Consumption | 10 W |
| Supported Operating Systems | macOS 10.13, 10.14 or Later Windows 7, 8.1, 10 (All 64-Bit) Linux |
| Computer Interface | PCI Express 4 Lane Generation 2 (Compatible with 4, 8 and 16 Lane PCI Express Slots) |
| Sync Input | Tri-Sync or Black Burst |
| SDI Compliance | SMPTE 259M, SMPTE 292M, SMPTE 296M, SMPTE 372M, SMPTE 425M, ITU-R BT.656, ITU-R BT.601 |
| Audio Channels | 16 x Embedded, HD and SD (Input and Output) |
| SDI Metadata Support | RP 188/SMPTE 12M-2 and Closed Captioning |
| Video Support | HD: 1080p: 23.98, 24, 25, 29.97, 30, 50, 59.94, 60 1080PsF: 23.98, 24, 25, 29.97, 30 1080i: 50, 59.94, 60 720p: 50, 59.94, 60 SD: 525i: 59.94 NTSC 625i: 50 PAL |
| SDI Video Sampling | 8, 10, 12-Bit RGB 4:4:4 (In All Modes up to 1080p30) 8, 10-Bit YUV 4:2:2 (In All Modes) 12-Bit RGB 4:4:4 (Supported in Playback Mode Only) |
| Audio Sample Rate | 24-Bit, 48 kHz |
| Color Space | Rec. 601, Rec. 709 |
| Supported Codecs | AVC-Intra, AVCHD, Canon XF MPEG2, Digital SLR, DV-NTSC, DV-PAL, DVCPRO50, DVCPROHD, DPX, HDV, HEVC, XDCAM EX, XDCAM HD, XDCAM HD422, DNxHR & DNxHD, Apple ProRes 4444, Apple ProRes 422 HQ, Apple ProRes 422, Apple ProRes LT, Apple ProRes 422 Proxy, Uncompressed 8-Bit 4:2:2, Uncompressed 10-Bit 4:2:2, Uncompressed 10-Bit 4:4:4 |
| Conversion Modes | Playback: 720p to 1080p, 1080p to 720p Up Conversion: SD to 720p or 1080p (Selectable: 4:3, 14:9 Zoom, and 16:9 Zoom) Down Conversion: SD (Selectable: Letterbox and Anamorphic 16:9) Color Space Conversion: Hardware-Based, Real-Time |
| SDI Color Precision | 8, 10, 12-Bit RGB 4:4:4 (In All Modes up to 1080p30) 8, 10-Bit YUV 4:2:2 (In All Modes) 12-Bit RGB 4:4:4 (Supported in Playback Mode Only) |
| Relative Humidity (non-condensing) | 0 to 90% |
| Packaging Info | |
| Package Weight | 0.35 lb |
| Box Dimensions (LxWxH) | 5.3 x 4.15 x 1.15" |
| Others | |
| Marka | Blackmagic Design |
