| General | |
|---|---|
| Dimensions | 4.7" / 11.94 cm |
| Weight | 3.17 oz / 90 g |
| Packaging Info | |
| Package Weight | 0.37 lb |
| Box Dimensions (LxWxH) | 5.45 x 5.35 x 1.1" |
| Environmental | |
| Operating Temperature | 32 to 104°F / 0 to 40°C |
| Operating Humidity | 0 to 90% |
| Storage Temperature | -4 to 113°F / -20 to 45°C |
| Power | |
| Power Consumption | 10 W |
| Inputs/Outputs | |
| System Connection | PCIe 2.0 x4 |
| Audio Outputs | No |
| Video Outputs | 1x BNC (6G-SDI) Female 1x HDMI (2.0a) Female |
| Format Support | |
| Embedded Audio | SDI: 16-Channel HDMI: 8-Channel |
| Output Video Format | SDI (8/10-Bit 4:2:2 YUV) DCI 4K at 23.98/24/25 fps UHD 4K at 23.98/24/25/29.97/30 fps DCI 2K at 23.98/24/25 fps DCI 2KPsF at 23.98/24/25 fps SDI (8/10/12-Bit 4:4:4 RGB) 1080p at 23.98/24/25/29.97/30/50/59.94/60 fps 1080PsF at 23.98/24/25/29.97/30 fps 1080i at 50/59.94/60 fps 720p at 50/59.94/60 fps 576i / 625 lines 480i / 525 lines HDMI (8/10/12-Bit 4:4:4/4:2:2/4:2:0) DCI 4K at 23.98/24/25 fps UHD 4K at 23.98/24/25/29.97/30 fps 1080p at 23.98/24/25/29.97/30/50/59.94/60 fps 1080PsF at 23.98/24/25/29.97/30 fps 1080i at 50/59.94/60 fps 720p at 50/59.94/60 fps 576i / 625 lines 480i / 525 lines |
| Standards | |
| HDR Support | : |
| Video Standard Compliance | SMPTE 259M/292M/296M/372M/425M/ST-2081 ITU -R BT.601/BT.656 |
| Hardware | |
| OS Compatibility | Windows 7 or Later macOS 10.14 or Later Linux |
| Others | |
| Marka | Blackmagic Design |
Price:
13.573,63 ₺
