| General | |
|---|---|
| Certifications | C-Tick, CE, FCC |
| Dimensions | 3.42" / 86.87 mm |
| Weight | 0.22 lb / 0.1 kg |
| Packaging Info | |
| Package Weight | 0.75 lb |
| Box Dimensions (LxWxH) | 5.6 x 5.45 x 2.15" |
| Environmental | |
| Operating Temperature | 32 to 104°F / 0 to 40°C |
| Storage Temperature | -4 to 113°F / -20 to 45°C |
| Power | |
| Power Consumption | Device: 17 W |
| Inputs/Outputs | |
| System Connection | PCIe 4.0 x4 |
| Video Inputs | 1x HDMI (1.4b) Female |
| Video Outputs | 1x HDMI (1.4b) Female |
| Simultaneous Multi-Input Support | Not Specified by Manufacturer |
| Format Support | |
| Input Video Format | HDMI (8/10-Bit 4:4:4/4:2:2/4:2:0 RGB, YUV) 720p at 50/59.94/60 fps 1080p 23.98/24/25/29.97/50/59.94/60 fps 1080i 50/59.94/60 fps UHD 4K 23.98/24/25/29.97/30 fps SDI 576i / 625 lines at 50 fps 480i / 525 lines 59.94 fps |
| Output Audio Format | Analog: 48 kHz / 24-Bit |
| Output Video Format | HDMI (8/10-Bit 4:4:4/4:2:2/4:2:0 RGB, YUV) 720p at 50/59.94/60 fps 1080p 23.98/24/25/29.97/30/50/59.94/60 fps 1080i 50/59.94/60 fps UHD 4K 23.98/24/25/29.97/30 fps SDI 576i / 625 lines at 50 fps 480i / 525 lines 59.94 fps |
| Input Audio Format | Analog: 48 kHz / 24-Bit |
| Standards | |
| HDR Support | Not Specified by Manufacturer |
| Hardware | |
| OS Compatibility | Windows 8.1 Windows 10 macOS 10.14 or Later Linux |
| Others | |
| Marka | Blackmagic Design |
