| General | |
|---|---|
| Dimensions | 3.13 x 1.8 x 0.98" / 79.5 x 45.7 x 24.89 mm |
| Weight | 5.9 oz / 167 g |
| Packaging Info | |
| Package Weight | 0.95 lb |
| Box Dimensions (LxWxH) | 5.75 x 4.85 x 2.9" |
| Environmental | |
| Operating Temperature | 32 to 72°F / 0 to 40°C |
| Operating Humidity | 0 to 90% |
| Storage Temperature | -4 to 140°F / -20 to 60°C |
| Power | |
| Power Consumption | 2.5 W |
| Power I/O | 1x USB-C (4.4 to 5.2 VDC ) Input |
| Inputs/Outputs | |
| Other I/O | 1x USB-C Input |
| Video Inputs | 1x BNC (3G-SDI) 1x HDMI (2.0) |
| Audio Inputs | No |
| Audio Outputs | No |
| Video Outputs | 1x BNC (3G-SDI) 1x HDMI (2.0) |
| Expansion Slots | No |
| Format Support | |
| Embedded Audio | HDMI/SDI |
| Input Video Format | SDI (8/10-Bit 4:2:2 RGB, YUV) DCI 2K at 23.98/24/25/29.97/30/47.95/48/50/59.94/60 fps DCI 2KPsF at 25/29.97/30 fps 1080p at 23.98/24/25/29.97/30/47.95/48/50/59.94/60 fps 1080PsF at 25/29.97/30 fps 1080i at 50/59.94/60 fps 720p at 50/59.94/60 fps 480i / 525 lines at 59.94 fps 576i / 625 lines at 50 fps HDMI (8/10-Bit 4:2:2 RGB, YUV) 1080p at 23.98/24/25/29.97/30/47.95/48/50/59.94/60 fps 1080i at 50/59.94/60 fps 720p at 50/59.94/60 fps 480i / 525 lines at 29.97 fps 576i / 625 lines at 25 fps |
| Output Video Format | SDI (8/10-Bit 4:2:2 RGB, YUV) DCI 2K at 23.98/24/25/29.97/30/47.95/48/50/59.94/60 fps DCI 2KPsF at 25/29.97/30 fps 1080p at 23.98/24/25/29.97/30/47.95/48/50/59.94/60 fps 1080PsF at 25/29.97/30 fps 1080i at 50/59.94/60 fps 720p at 50/59.94/60 fps 480i / 525 lines at 29.97 fps 576i / 625 lines at 25 fps |
| Standards | |
| HDR Support | No |
| Video Standard Compliance | SMPTE 259M/292M/296M/424M/425M-A/425M-B |
| Hardware | |
| OS Compatibility | macOS 10.15 macOS 11.1 or Later Windows 10 (64-Bit Only) |
| Wireless | No |
| Tally Light | No |
| Others | |
| Marka | Blackmagic Design |
Price:
5.817,26 ₺
