| General | |
|---|---|
| Dimensions | 4.33 x 2.32 x 0.9" / 109.98 x 58.93 x 22.86 mm |
| Weight | 7.4 oz / 210 g |
| Packaging Info | |
| Package Weight | 0.935 lb |
| Box Dimensions (LxWxH) | 6.1 x 4.7 x 2.8" |
| Environmental | |
| Operating Temperature | 32 to 104°F / 0 to 40°C |
| Operating Humidity | 0 to 90% |
| Storage Temperature | -4 to 113°F / -20 to 45°C |
| Power | |
| Power Consumption | Power Supply: 2 W |
| Power I/O | 1x Barrel (6 to 36 VDC ) Input |
| Inputs/Outputs | |
| Video Inputs | 1x BNC (12G-SDI) |
| Video Outputs | 1x BNC (12G-SDI) |
| Expansion Slots | 1x SFP Slot |
| Format Support | |
| Embedded Audio | Fiber Input: 16-Channel Fiber Output: 16-Channel |
| Input Video Format | SDI (4:4:4/4:2:2 RGB, YUV) DCI 4K at 23.98/24/25 fps UHD 4K 23.98/24/25/29.97/30/50/59.94/60 fps DCI 2K 23.98/24/25 fps DCI 2KPsF 23.98/24/25 fps 1080p 23.98/24/25/29.97/30/50/59.94/60 fps 1080PsF 23.98/24/25/29.97/30 fps 1080i 50/59.94/60 fps |
| Output Video Format | SDI (10-Bit 4:4:4/4:2:2 RGB, YUV) DCI 4K at 23.98/24/25 fps UHD 4K 23.98/24/25/29.97/30/50/59.94/60 fps DCI 2K 23.98/24/25 fps DCI 2KPsF 23.98/24/25 fps 1080p 23.98/24/25/29.97/30/50/59.94/60 fps 1080PsF 23.98/24/25/29.97/30 fps 1080i 50/59.94/60 fps |
| Standards | |
| HDR Support | Not Specified by Manufacturer |
| HDCP Support | No |
| Video Standard Compliance | SMPTE 259M/292M/296M/297M/424M-B/425M/ST-2081 ITU -R BT.601 |
| Hardware | |
| OS Compatibility | Windows 10 (64-Bit Only) macOS 10.15 to 11.1 |
| Others | |
| Marka | Blackmagic Design |
