| General | |
|---|---|
| Dimensions | 6.7 x 5.5 x 1.8" / 170.2 x 139.7 x 45.7 mm |
| Weight | 1.28 lb / 581 g |
| Operating Conditions | 32 to 104°F / 0 to 40°C up to 90% Humidity |
| Storage Conditions | -4 to 140°F / -20 to 60°C up to 90% Humidity |
| Packaging Info | |
| Package Weight | 2.2 lb |
| Box Dimensions (LxWxH) | 9 x 7.7 x 2.5" |
| Power | |
| Power Consumption | Power Supply: 100 to 240 VAC (16 W) |
| Power I/O | 1x IEC C14 Input |
| ESD Protection | No |
| Standards | |
| HDR Support | No |
| HDCP Support | No |
| Video Standard Compliance | SMPTE 259M/292M/296M/372M/424M/425M/ST-2081-1/ST-2081-10/ST-2082-1/ST-2082-10 |
| Reclocking | Yes |
| EDID Support | No |
| Interfaces | |
| Other I/O | 1x RJ45 (10/100 Mbps Ethernet) Input/Output 1x Mini-USB (Firmware) Input |
| Embedded Audio | SDI: 16-Channel |
| Inputs | 1 x BNC (12G-SDI) Female |
| Outputs | 8x BNC (12G-SDI) Female |
| Transmission | |
| Video Format | SDI (4:4:4/4:2:2) 4096 x 2160: 23.98/24/25 fps 3840 x 2160: 23.98/24/25/29.97/30/50/59.94/60 fps 2048 x 1080p: 23.98/24/25 fps 2048 x 1080PsF: 23.98/24/25 fps 1920 x 1080p: 23.98/24/25/29.97/30/50/59.94/60 fps 1920 x 1080PsF: 23.98/24/25/29.97/30 fps 1280 x 720p: 50/59.94/60 fps 720 x 576i: 50 fps 720 x 480i: 59.94 fps |
| Audio Format | Unspecified Digital Signal: 48 kHz / 24-Bit |
| Others | |
| Marka | Blackmagic Design |
Price:
39.058,80 ₺
