| General | |
|---|---|
| Dimensions | W x H x D: 5.5 x 1.8 x 6.7" (14 x 4.6 x 17 cm) (with SDI port included) |
| Weight | 1.3 lb (0.6 kg) |
| Operating Temperature | 32 to 104°F (0 to 40°C) |
| Power Supply | 1x built-in international AC power supply with IEC C14 inlet IEC power cable required (not included) 90 - 240 VAC input |
| Storage Temperature | -4 to 140°F (-20 to 60°C) |
| Power Consumption | 15 W |
| SDI Video Input | 1x SDI on BNC 12G-SDI SD/HD/2K/4K auto switching |
| Optical Fiber Support | Supports optional optical fiber module |
| Analog Audio Output | 2 channels professional balanced analog audio via XLR connectors Right XLR can be configured for timecode output |
| HDMI Output | 1x HDMI 2.0 type A |
| SDI Compliance | SMPTE 292M, SMPTE 259M, SMPTE 296M, SMPTE 372M, SMPTE 424M-B, SMPTE 425M, SMPTE 297M for Optical Fiber SDI |
| AES/EBU Audio Output | 4 channels professional 110 ohm balanced digital audio via XLR connectors Right XLR can be configured for timecode output |
| Relative Humidity | 0 to 90% non-condensing |
| Updates and Configuration | USB or Ethernet |
| Multi Rate Support | Automatic switching between SD, HD, 2K, and 4K |
| SDI Video Sampling | 4:2:2 and 4:4:4 |
| Internal Software Upgrade | Via included updater application |
| SDI Audio Sampling | Television standard sample rate of 48 kHz and 24-bit |
| Re-Clocking | Yes |
| SD Format Support | 525/29.97 NTSC, 625/25 PAL |
| SDI Color Space | YUV and RGB |
| SDI Video Rates | SDI video connections are auto switching between SD-SDI, HD-SDI, high definition level B 3G-SDI, 6G-SDI, and 12G-SDI |
| HD Format Support | 1280 x 720p50, 1280 x 720p59.94, 1280 x 720p60, 1920 x 1080i50, 1920 x 1080i59.94, 1920 x 1080i60, 1920 x 1080p23.98, 1920 x 1080p24, 1920 x 1080p25, 1920 x 1080p29.97, 1920 x 1080p30, 1920 x 1080p50, 1920 x 1080p59.94, 1920 x 1080p60 |
| SDI Color Precision | 4:2:2 and 4:4:4 |
| 2K Format Support | 2048 x 1080PsF23.98, 2048 x 1080PsF24, 2048 x 1080PsF25, 2048 x 1080p23.98, 2048 x 1080p24, 2048 x 1080p25 |
| 4K Format Support | 3840 x 2160p23.98, 3840 x 2160p24, 3840 x 2160p25, 3840 x 2160p29.97, 3840 x 2160p30, 3840 x 2160p50, 3840 x 2160p59.94, 3840 x 2160p60, 4096 x 2160p23.98, 4096 x 2160p24, 4096 x 2160p25, 4096 x 2160p29.97, 4096 x 2160p30, 4096 x 2160p50, 4096 x 2160p59.94, 4096 x 2160p60 |
| Operational Voltage Range | 90 - 240 VAC |
| HDMI Format Support | 525/29.97 NTSC, 625/25 PAL, 1280 x 720p50, 1280 x 720p59.94, 1280 x 720p60, 1920 x 1080i50, 1920 x 1080i59.94, 1920 x 1080i60, 1920 x 1080p23.98, 1920 x 1080p24, 1920 x 1080p25, 1920 x 1080p29.97, 1920 x 1080p30, 1920 x 1080p50, 1920 x 1080p59.94, 1920 x 1080p60, 2048 x 1080p23.98, 2048 x 1080p24, 2048 x 1080p25, 3840 x 2160p23.98, 3840 x 2160p24, 3840 x 2160p25, 3840 x 2160p29.97, 3840 x 2160p30, 3840 x 2160p50, 3840 x 2160p59.94, 3840 x 2160p60, 4096 x 2160p23.98, 4096 x 2160p24, 4096 x 2160p25, 4096 x 2160p29.97, 4096 x 2160p30, 4096 x 2160p50, 4096 x 2160p59.94, 4096 x 2160p60 |
| HDMI Color Space | REC 601, REC 709 |
| HDMI Color Precision | YUV 4:2:2 and RGB 4:4:4 in HD, 2K, and 4K |
| Software Control | Mac OS X and Windows software upgrade via USB and Ethernet |
| Basic Settings Control | Mini Switches, USB, and Ethernet via free software utility |
| Power Over Ethernet | Can be powered via 48 VDC using PoE (Power-over-Ethernet) |
| Packaging Info | |
| Package Weight | 1.825 lb |
| Box Dimensions (LxWxH) | 10.8 x 7.6 x 2.6" |
| Others | |
| Marka | Blackmagic Design |
Price:
38.172,36 ₺
