| General | |
|---|---|
| Dimensions | 4.7 x 2.6 x 1.1" / 11.9 x 6.6 x 2.8 cm |
| Weight | 7.23 oz / 205 g |
| Operating Conditions | 41 to 104°F / 5 to 40°C up to 90% Humidity |
| Storage Conditions | -4 to 113°F / -20 to 45°C up to 90% Humidity |
| Packaging Info | |
| Package Weight | 1.35 lb |
| Box Dimensions (LxWxH) | 7.4 x 6.7 x 2" |
| Power | |
| Power Consumption | Device: 12 to 16 VDC (18 W) |
| Power I/O | 1x Barrel (12 to 16 VDC ) Input |
| PoE Support | Yes: PoE++ 802.3bt |
| Inputs/Outputs | |
| Video I/O | Input 1x RJ45 Female Output 1x HDMI Female |
| Audio I/O | No |
| Other I/O | Input 1x USB-C (Firmware) |
| Expansion Slots | No |
| Format Support | |
| Video Resolution | RJ45 Input (4:2:2 YUV) 4096 x 2160 at 23.98/24/25/29.97/30/47.95/48/50/59.94/60 fps 3840 x 2160 at 23.98/24/25/29.97/30/47.95/48/50/59.94/60 fps 2048 x 1080 at 23.98/24/25/29.97/30/47.95/48/50/59.94/60 fps 1920 x 1080p at 23.98/24/25/29.97/30/47.95/48/50/60 fps 1920 x 1080PsF at 25/29.97/30 fps 1920 x 1080i at 25/29.97/30 fps 1280 x 720 at 50/59.94/60 fps 720 x 480i at 59.94 fps 720 x 576i at 50 fps |
| Embedded Audio | HDMI/LAN (RJ45) |
| Standards | |
| HDR Support | Yes |
| HDCP Support | No |
| Video Standard Compliance | SMPTE: ST 2110-20/ST 2110-21 |
| Hardware | |
| OS Compatibility | macOS 13 or Later Windows 10 to 11 |
| Wireless | No |
| Others | |
| Marka | Blackmagic Design |
