| General | |
|---|---|
| Dimensions | 5.75 x 2.91 x 1.34" / 14.61 x 7.39 x 3.4 cm |
| Weight | 10.41 oz / 295 g |
| Operating Conditions | 41 to 104°F / 5 to 40°C up to 90% Humidity |
| Storage Conditions | -4 to 113°F / -20 to 45°C up to 90% Humidity |
| Packaging Info | |
| Package Weight | 1.56 lb |
| Box Dimensions (LxWxH) | 10.4 x 3.3 x 2.5" |
| Power | |
| Power I/O | 1x Barrel (12 VDC ) Input |
| PoE Support | Yes: PoE++ 802.3bt |
| Inputs/Outputs | |
| Video I/O | Input 1x BNC (12G-SDI) Female Output 1x BNC (12G-SDI) Female |
| Audio I/O | Input 1x XLR 5-Pin Analog Female Output 1x XLR 5-Pin Analog Female |
| Other I/O | Input/Output 1x RJ45 (10 GbE) Input 1x USB-C (Firmware) 1x USB-C (Device) |
| Expansion Slots | No |
| Format Support | |
| Video Resolution | BNC Input/Output (4:2:2) 4096 x 2160 up to 23.98/24/25/29.97/30/47.95/48/50/59.94/60 fps 3840 x 2160 up to 23.98/24/25/29.97/30/47.95/48/50/59.94/60 fps 1920 x 1080p up to 23.98/24/25/29.97/30/47.95/48/50/59.94/60 fps 1920 x 1080PsF at 25/29.97/30 fps 1920 x 1080i at 50/59.94/60 fps 1280 x 720 at 50/59.94/60 fps |
| Embedded Audio | LAN (RJ45)/SDI |
| Standards | |
| HDCP Support | No |
| Hardware | |
| Wireless | No |
| Others | |
| Marka | Blackmagic Design |
Price:
26.316,22 ₺
