| General | |
|---|---|
| Dimensions | Transmitter: 4.5 x 2.7 x 1.4" / 114.8 x 69 x 35.5 mm Receiver: 5.6 x 3.4 x 1.3" / 142 x 87.2 x 33.2 mm |
| Weight | Transmitter: 7.4 oz / 210.00 g Receiver: 15.5 oz / 440.00 g |
| Environmental Resistance | No |
| Status Display | On Receiver Only |
| Packaging Info | |
| Package Weight | 7.02 lb |
| Box Dimensions (LxWxH) | 16.6 x 14.5 x 7" |
| Power | |
| Power Consumption | Transmitter: 10 W Receiver: 11 W |
| Input Power | 6 to 16 VDC |
| Battery | Receiver: 1x V-Mount on Fixed Plate Transmitter: 1x L-Series Mount on Fixed Plate |
| Inputs/Outputs | |
| Video I/O | Transmitter: 1x HDMI 1.4b Input Transmitter: 1x BNC (3G-SDI) Input Transmitter: 1x BNC (3G-SDI) Loop Output Receiver: 2x HDMI 1.4b Output Receiver: 2x BNC (3G-SDI) Output |
| Antenna I/O | Transmitter/Receiver: 2x RP-SMA |
| Audio I/O | No |
| Other I/O | Transmitter/Receiver: 1x USB-C Receiver: 1x RJ45 (10/100 Ethernet) |
| Embedded Audio | HDMI/SDI |
| Power I/O | Transmitter/Receiver: 1x Barrel Input |
| Encryption | No |
| Format Support | |
| Video Format | HDMI/SDI 1080p: 60/59.94/50/30/29.97/25/24/23.98 1080i: 60/59.94/50 720p: 60/59.94/50 |
| Audio Format | Not Specified by Manufacturer |
| Timecode Support | No |
| Wireless | |
| Wi-Fi | Yes |
| Bluetooth | No |
| Mobile App Compatible | No |
| Wireless Range | 3000' / 914.4 m |
| Channel Bandwidth | 40 MHz |
| Frequency Range | 5.1 to 5.85 GHz |
| Latency | 33 ms |
| RF Power | < 23 dBm |
| RF Sensitivity | -90 dBm |
| Cellular Support | No |
| Mounting | |
| Tripod/Accessory Mounting | Receiver/Transmitter, Bottom 1x 1/4"-20 Female |
| Others | |
| Marka | HollyLand |
Price:
80.980,26 ₺
