| General | |
|---|---|
| Dimensions | 5.9 x 4.3 x 5.2" (151 × 108 × 132 mm) |
| Weight | 449 g (15.8 oz) |
| Operating Temperature | -4 to 104°F (-20 to 40°C) |
| Storage Temperature | -4 to 104°F (-20 to 40°C) |
| Packaging Info | |
| Package Weight | 2.525 lb |
| Box Dimensions (LxWxH) | 7.45 x 5.6 x 5.6" |
| Gimbal | |
| Number of Axes | 3-axis |
| Angular Vibration Range | ± 0.005° |
| Mount | Detachable |
| Control Range | Tilt: 40 to -125° Pan: ± 300° Roll: ± 20° |
| Manual Control Speed | Tilt: 180°/s Roll: 180°/s Pan: 360°/s |
| Camera | |
| Sensor Size | Still: 0.9 x 0.6" (23.5 x 15.7 mm) Video: 0.9 x 0.5" (23.5 x 12.5 mm), max recording area |
| Lens Mount | DL |
| Photo Resolution | 24 MP |
| Video Resolution | Aspect Ratio 17:9 Cinema-DNG: 6K: 6016×3200, 23.976/24/25/29.97/30p, 12-bit, full FOV C4K: 4096×2160, 23.976/24/25/29.97/30p, 12-bit, full FOV 4K: 3944×2088, 47.95/50/59.94, 12-bit, narrow FOV ProRes: 4K: 4096×2160, 23.976/24/25/29.97/30p, 10-bit, HQ, full FOV 2K: 2048×1080, 47.95/50/59.94p, 10-bit, HQ/XQ, narrow FOV H.264: C4K: 4096×2160, 24/25/30/48/50/59.94p H.265: C4K: 4096×2160, 24/25/30p Aspect Ratio 16:9 Cinema-DNG: 6K: 5760×3240, 23.976/24/25/29.97/30p, 12-bit, full FOV 4K: 3840×2160, 23.976/24/25/29.97/30p, 12-bit, full FOV 4K: 3712×2088, 47.95/50/59.94, 12-bit, narrow FOV ProRes: 4K: 3840×2160, 23.976/24/25/29.97p, 10-bit, HQ/XQ, full FOV 2.7K: 2704×1520, 47.95/50/59.94p, 10-bit, HQ, narrow FOV FHD:1920×1080, 47.95/50/59.94p, 10-bit, HQ/XQ, narrow FOV H.264: 4K: 3840×2160, 24/25/30/48/50/59.94p 2.7K: 2720×1530, 24/25/30/48/50/59.94p FHD: 1920×1080, 24/25/30/48/50/59.94p HD: 1280×720, 24/25/30/48/50/59.94p H.265: 4K: 3840×2160, 24/25/30p 2.7K: 2720×1530, 24/25/30/48/50/59.94p FHD: 1920×1080, 24/25/30/48/50/59.94p HD: 1280×720, 24/25/30/48/50/59.94p Aspect Ratio 2.44:1 ProRes: 5.2K: 5280×2160, 23.976/24/25/29.97/30p, 10-bit, HQ, full FOV H.264/H.265: 4K: 3840×1572, 30p, full FOV |
| Photo Modes | Single shot Burst: 3, 5, 7, or 10 frames Auto Exposure (AE) Bracketing: 3/5 bracketed frames at 0.7 EV bias Interval: 5, 7, 10, or 14 fps (up to 20 fps when using RAW burst) |
| ISO Range | Photo: 100 to 25600 Video: 100 to 1600 (EI mode on); 100 to 6400 (EI mode off) |
| Shutter Speed | Electronic Shutter Speed: 1/8000 to 8 seconds Mechanical Shutter Speed: 1/1000 to 8 seconds (DJI DL-S 16mm F2.8 ND ASPH not supported) |
| Supported File Types | Photo: DJI CINESSD: DNG microSD: DNG, JPEG, DNG+JPEG Video: CINESSD: Cinema-DNG, ProRes microSD: MOV, MP4 |
| Recording Media | microSD: Class 10 or UHS-1 rating with a writing speed of 15 MB/s required (up to 64 GB) SSD: DJI CINESSD |
| Others | |
| Marka | DJI |
