| General | |
|---|---|
| Compatibility | DJI RS 3 Gimbal Stabilizer / RS 4 Gimbal Stabilizer / RS 3 Pro Gimbal Stabilizer / RS 4 Pro Gimbal Stabilizer / Focus Pro Grip / Focus Pro Hand Unit / Ronin 4D Flex |
| Speed | 300 rpm (Max) |
| Max Transmission Distance | 524.9' / 160 m |
| Max Torque | 0.6 Nm |
| Gear Specs | 30 Teeth, 0.8 MOD |
| Packaging Info | |
| Package Weight | 0.715 lb |
| Box Dimensions (LxWxH) | 8.2 x 3.6 x 1.7" |
| Physical | |
| Dimensions | 3.9 x 2.4 x 1.3" / 100 x 61 x 34 mm |
| Weight | 4.3 oz / 123 g |
| Cable Length | 11.8" / 30 cm |
| Mounting | 1x 15mm Rod 1x 1/4"-20 Screw 1x Rod Mount Kit |
| Operating Conditions | -4 to 113°F / -20 to 45°C |
| Certifications | CE, FCC |
| Power | |
| Power Source | USB |
| DC Input Power | 6.6 to 17.2 VDC |
| Inputs/Outputs | |
| Media/Memory Card Slot | Yes |
| USB I/O | 1 x USB-C Female Input |
| Internal Storage | Yes |
| Wireless | |
| Wireless | 2.4 GHz Radio/RF |
| Others | |
| Marka | DJI |
