| General | |
|---|---|
| Dimensions | 5.5 x 3.9 x 5.2" / 14 x 9.8 x 13.2 cm |
| Weight | 1 lb / 461 g (with Lens) |
| Operating Temperature | 14 to 104°F / -10 to 40° |
| Storage Temperature | -4 to 140°F / -20 to 60°C |
| Packaging Info | |
| Package Weight | 2.58 lb |
| Box Dimensions (LxWxH) | 7.4 x 5.75 x 5.65" |
| Gimbal | |
| Angular Vibration Range | ±0.01° |
| Controllable Range | Tilt: 40 to -130° Pan: 320° Roll: 20° |
| Mechanical Range | Tilt: 50 to -140° Pan: 330° Roll: 90 to -50° |
| Controllable Speed | Tilt: 180°/s Pan: 270°/s Roll: 180°/s |
| Camera | |
| Sensor | 4/3" CMOS |
| Effective Pixels | 20.8 MP |
| Photo Resolutions | 5280 x 2970 (16:9) 5280 x 3956 (4:3) |
| Video Resolutions | 17:9 Aspect Ratio: CinemaDNG: 4096 x 2160 at 23.976/24/25/29.97 (up to 2.4Gb/s) 4096 x 2160 at 50/59.94 (up to 4 Gb/s) H.264: 4096 x 2160 at 23.976/24/25/29.97/47.95/50/59.94 (100 Mb/s) H.265: 4096 x 2160 at 23.976/24/25/29.97 (100 Mb/s) 16:9 Aspect Ratio: CinemaDNG: 3840 x 2160 at 23.976/24/25/29.97 (up to 2.4 Gb/s) 3840 x 2160 at 50/59.94 (up to 4 Gb/s) ProRes: 3840 x 2160 at 23.976/24/25/29.97 422 HQ at 900 Mb/s, 4444 XQ at 2 Gb/s H.264: 3840 x 2160 at 23.976/24/25/29.97/47.95/50/59.94 (100 Mb/s) 2720 x 1530 at 23.976/24/25/29.97p (80 Mb/s) 2720 x 1530 at 47.95/50/59.94p (100 Mb/s) 1920 x 1080 at 23.976/24/25/29.97p (60 Mb/s) 1920 x 1080 at 47.95/50/59.94p (80 Mb/s) 1920 x 1080 at 119.88p (100 Mb/s) H.265: 3840 x 2160 at 23.976/24/25/29.97 (100 Mb/s) 2720 x 1530 at 23.976/24/25/29.97p (65 Mb/s) 2720 x 1530 at 47.95/50/59.94p (80 Mb/s) 1920 x 1080 at 23.976/24/25/29.97p (50 Mb/s) 1920 x 1080 at 47.95/50/59.94p (65 Mb/s) 1920 x 1080 at 119.88p (100 Mb/s) 2.44:1 Aspect Ratio: CinemaDNG: 5280 x 2972 at 23.976/24/25/29.97 (up to 4.2 Gb/s) ProRes: 5280 x 2160 at 23.976/24/25/29.97 422 HQ at 1.3 Gb/s H.264/H.265: 3840 x 1572 at 23.976/24/25/29.97 (100 Mb/s) |
| Photo Formats | DNG,JPEG,DNG+JPEG |
| Video Formats | RAW,ProRes,MOV,MP4 |
| ISO Range | 100 to 6400 (Video) 100 to 25600 (Photo) |
| Exposure Modes | Auto, Manual, Shutter, Aperture |
| Exposure Compensation | ±3.0 (1/3 Increments) |
| Metering Modes | Center-Weighted, Spot (Area Option 12x8) |
| AE Lock Support | Yes |
| Electronic Shutter Speed | 8 to 1/8000s |
| White Balance | Auto, Sunny, Cloudy, Incandescent, Neon Custom (2000-10,000K) |
| Video Captions Support | Yes |
| Anti-Flicker | Auto, 50 Hz, 60 Hz |
| NTSC/PAL Support | Yes |
| Others | |
| Marka | DJI |
