| General | |
|---|---|
| Dimensions | 9 x 16.5 x 2.6" / 22.8 x 41.8 x 6.5 cm |
| Weight | 4.3 lb / 1.9 kg |
| Display | 4.3" TFT Color LCD (480 × 272) |
| Input | 1/4" Phone Jack Rated Input Level: -20 dBu Input Impedance: 550 Kilohms |
| Output | Output R Standard 1/4" Phone Jack Maximum Output Level: +11.4 dBu (Output Impedance 10 Kilohms or Higher) Output L/Mono (Phones) Standard 1/4" Phone Jack Maximum Output Level: +11.4 dBu (Output Impedance 10 Kilohms or Higher) |
| Frequency Response | 20 Hz to 20 kHz (±0.5 dB, 10-Kilohm Load) |
| Simultaneous Effects | 9 |
| Sampling Frequency | 44.1 kHz |
| A/D Conversion | 24-Bit with 128x Oversampling |
| Patch Memory | 240 User Patches |
| Signal Processing | 32-Bit |
| D/A Conversion | 24-Bit with 128x Oversampling |
| Noise Floor | Left and Right: -99.3 dBu Send: -99.0 dBu |
| S/N Ratio | 123 dB |
| Return | 1/4" Phone Jack Rated Input Level: -20 dBu Input Impedance: 1 Megohm |
| USB | Port: USB 2.0 Micro-B Guitar Lab: USB 1.1 Full Speed Audio Interface: USB 2.0 Full Speed, 44.1 kHz / 32-Bit, 2-In, 2-Out |
| Aux Input | Stereo Mini Jack: 3.5 mm Rated Input Level: -10 dBu Input Impedance (Line): 10 Kilohms |
| Send | Standard Stereo Phone Jack Maximum Output Level: +11.4 dBu (when Output Impedance 10 Kilohms or Higher) |
| Control Input | FP02M Expression Pedal Input |
| Headphone | 24 mW + 24 mW (at 32-Ohm Load) |
| Power Adapter | AC Adapter: 9 VDC (Center Minus Plug), 500 mA (ZOOM AD-16) |
| SD Card | Standards: Cards Supporting SD/SDHC/SDXC Specifications (Class 10 or Higher) Looper: 44.1 kHz / 16-Bit Stereo WAV IR: 44.1 to 192 kHz, 16- / 24- / 32-Bit WAV |
| Packaging Info | |
| Package Weight | 6.745 lb |
| Box Dimensions (LxWxH) | 21.4 x 12.8 x 3.7" |
| Others | |
| Marka | Zoom |
