| General | |
|---|---|
| Dimensions | 4.8 x 3.1 x 1.2" / 123.0 x 79.5 x 29.5 mm |
| Weight | 8.53 oz / 0.24 kg |
| Operating Conditions | 32 to 104°F / 0 to 40°C up to 90% Humidity |
| Storage Conditions | -4 to 113°F / -20 to 45°C |
| Packaging Info | |
| Package Weight | 1.07 lb |
| Box Dimensions (LxWxH) | 5.75 x 5.55 x 2.55" |
| Power | |
| Power Consumption | 6 to 36 VDC (5.5 W) |
| Power I/O | 1x Barrel Input |
| Standards | |
| HDR Support | No |
| HDCP Support | No |
| Video Standard Compliance | SMPTE 259M/292M/296M/310M/425M-B ITU -R BT.601/BT.656 |
| Reclocking | No |
| EDID Support | Yes |
| OS Compatibility | macOS 10.15 macOS 11.1 or Later Windows 10 or Later (64-Bit Only) |
| Interfaces | |
| Embedded Audio | SDI |
| Inputs | 4 x BNC (3G-SDI) |
| Outputs | 1x BNC (3G-SDI) 1x HDMI |
| Transmission | |
| Video Format | SDI (10-Bit 4:4:4/4:2:2 YUV, RGB) 2048 x 1080 1920 x 1080p: 24/25/23.98/29.97/30/59.94/60/50 fps 1920 x 1080PsF: 24/23.98 fps 1920 x 1080i: 59.94/60/50 fps 1280 x 720p: 59.94/60/50 fps |
| Maximum Sampling Rate | 48 kHz / 24-Bit |
| Others | |
| Marka | Blackmagic Design |
