| General | |
|---|---|
| Certifications | FCC Class A |
| Dimensions | 19.0 x 6.0 x 1.7" / 482.6 x 152.4 x 43.2 mm |
| Weight | 5.07 lb / 2.3 kg |
| Operating Conditions | 32 to 104°F / 0 to 40°C up to 90% Humidity |
| Storage Conditions | -4 to 113°F / -20 to 45°C |
| Material of Construction | Metal |
| Rack Form Factor | 1 U |
| Packaging Info | |
| Package Weight | 5.52 lb |
| Box Dimensions (LxWxH) | 19.4 x 7.4 x 3.3" |
| Power | |
| Power Consumption | 90 to 240 VAC (45 W) |
| Power I/O | 1x IEC C14 Input |
| Standards | |
| HDR Support | No |
| HDCP Support | Yes |
| Video Standard Compliance | SMPTE 259M/292M/296M/425M-B ITU -R BT.601/BT.656 |
| Reclocking | Yes |
| EDID Support | Yes |
| OS Compatibility | macOS 10.15 to 11.1 or Later Windows 10 (64-Bit Only) |
| Interfaces | |
| Other I/O | 1x RJ45 (RS-422) 1x RJ45 (10/100 Mbps Ethernet) 1x Mini-USB 2.0 |
| Embedded Audio | SDI |
| Inputs | 16 x BNC (3G-SDI / 6G-SDI / HD-SDI) |
| Outputs | 16x BNC (6G-SDI / HD-SDI / SD-SDI, Looping) 2x BNC (6G-SDI) 2x BNC (HD-SDI) 1x HDMI |
| Transmission | |
| Video Format | SDI (10-Bit 4:2:2 YUV, RGB) 4096 x 2160: 24 fps 3840 x 2160: 24/25/23.98/29.97/30 fps 2048 x 1080PsF: 24/25/23.98 fps 2048 x 1080: 24/25/23.98 fps 1920 x 1080p: 24/25/23.98/29.97/30/59.94/60/50 fps 1920 x 1080PsF: 24/25/23.98/29.97/30 fps 1920 x 1080i: 59.94/60/50 fps 1280 x 720p: 59.94/60/50 fps |
| Maximum Sampling Rate | 48 kHz / 24-Bit |
| Maximum Multiple Display Configuration | 4 x 4 |
| Maximum Data Rate | 6 Gb/s |
| Others | |
| Marka | Blackmagic Design |
