| General | |
|---|---|
| Dimensions | 8.3 x 5.1 x 13.2" / 21 x 13 x 33.5 cm |
| Weight | 8 lb / 3.6 kg |
| Display | 7" with 1920 x 1200 Resolution, 2000 cd/m², DCI-P3 100% HDR LCD |
| Operating Temperature | 32 to 104°F / 0 to 40°C |
| Power Supply | 1 x Internal 100-240 VAC 1 x 4-Pin XLR 12 VDC Input for External Power or Battery Use |
| Storage Temperature | -4 to 113°F / -20 to 60°C |
| Supported Operating Systems | Mac 10.13 High Sierra, 10.14 Mojave, or Later Windows 8.1 or 10 |
| SDI Video Inputs | 4 |
| Computer Interface | 1 x USB Type-C for Software Updates |
| Reference Input | Tri-Sync or Black Burst |
| SDI Video Outputs | 5 (12G-SDI A, B, C, D, and 3G-SDI Monitor Out) |
| SDI Data Rates | 270 MB/s, 1.5G, 3G, 6G, 12G |
| SDI Compliance | SMPTE 259M, SMPTE 292M, SMPTE 296M, SMPTE 372M, SMPTE 424M, SMPTE 425M Level A and B, SMPTE 2081-1, SMPTE 2081-10, SMPTE 2082-1, SMPTE 2082-10, SMPTE 2084 |
| Audio Sampling | Television Standard 24-Bit, 48 kHz Sample Rate |
| HDMI Video Inputs | 1 x HDMI 2.0 Type A |
| Remote Control | 1 x RS-422 Input 1 x RS-422 Output |
| Ethernet | 10 Gb/s |
| SDI Metadata Support | HD RP188 and Closed Captioning CEA-708, HDR Metadata Supported on SDI |
| Video Sampling | 4:2:2 YUV |
| Relative Humidity | 0 to 90% Non-Condensing |
| Multi Rate Support | Autodetection of SD, HD, 6G-SDI, 12G-SDI, 2SI Quad-Link 12G-SDI. |
| HDMI Video Outputs | 1 x HDMI 2.0 Type A |
| Analog Video Inputs | 1 x Component YUV on 3 BNCs 1 x Composite NTSC/PAL on 1 BNC |
| Color Space | Rec. 601, Rec. 709, Rec. 2020. 33-Point 3D LUTs Can Be Applied via the LUT Menu Tab. |
| Internal Software Upgrade | Loaded at System Start or via Blackmagic HyperDeck Setup Using USB Port |
| Color Precision | 10-Bit |
| Analog Video Outputs | None |
| Supported Codecs | ProRes HQ QuickTime, ProRes 422 QuickTime, ProRes LT QuickTime, ProRes Proxy QuickTime for All Formats up to 4320p60. H.265 High, H.265 Medium, H.265 Low for All Progressive Formats up to 4320p60. |
| Analog Audio Inputs | 4 Channels of Professional Balanced Analog Audio via XLR Connectors 2 Channels of Consumer Unbalanced via RCA connectors |
| Speaker | Built-In Mono Speaker |
| Timecode Input & Output | 1 x XLR Input 1 x XLR Output |
| SDI Audio Inputs | 16 Channels of Embedded Audio |
| SDI Audio Outputs | 16 Channels of Embedded Audio |
| Rack Compatibility | 3 RU, Half-Rack Width |
| HDMI Audio Inputs | 8 Channels of Embedded Audio |
| HDMI Audio Outputs | 8 Channels of Embedded Audio |
| Recorder Configuration | Via User Interface or Blackmagic HyperDeck Ethernet Protocol |
| External Recording Output | 1 x USB Type-C 3.1 Gen 2 (up to 10 Gb/s) for External Disk Recording |
| Copy Protection | HDMI Input is Unable to Capture from Copy Protected HDMI Sources. Always Confirm Copyright Ownership Before Capture or Distribution of Content. |
| SD Video Standards | 525i: 59.94 NTSC 625i: 50 PAL |
| HD Video Standards | 1080p: 60, 59.94, 50, 30, 29.97, 25, 24, 23.98 1080PsF: 30, 29.97, 25, 24, 23.98 1080i: 60, 59.94, 50 720p: 60, 59.94, 50 |
| 2K DCI Video Standards | 1080p: 25, 24, 23.98 1080PsF: 25, 24, 23.98 |
| UHD Video Standards | 2160: 60, 59.94, 50, 30, 29.97, 25, 24, 23.98 |
| 4K DCI Video Standards | 2160p: 25, 24, 23.98 |
| 8K Video Standards | 4320: 60, 59.94, 50, 30, 29.97, 25, 24, 23.98 |
| 8K DCI Video Standards | 4320p: 25, 24, 23.98 |
| Cache Recording | Slot for Optional M.2 PCIe NVMe Card for Cache Recording up to 16 GB/s. 60, 80, and 110 mm Supported. |
| Media | 2 x CFast 2.0 Card Slots and 1 x USB Type-C 3.1 Gen 2 Expansion Port for External Recording of SD, HD, UHD, and 8K. |
| Media Type | CFast Card and External USB Type-C Flash Drives |
| Media Format | Can Format Media to ExFAT (Windows/Mac) or HFS+ (Mac) File Systems |
| Scopes | Waveform, RGB Parade, Vector, and Histogram Scopes in Broadcast-Quality 10-Bit |
| Viewing Modes | Picture-in-Picture; Picture Overlay with Opacity Control. Waveform and RGB Parade with Standard and HDR Graticules; Vector with Zoom. |
| Control Panel | Integrated Capacitive Touchscreen LCD with On-Screen Controls for Settings and Navigating Menus. |
| External Control | RS-422 Deck Control, SDI Start/Stop, Timecode Run. Includes Blackmagic HyperDeck Ethernet Protocol. |
| Packaging Info | |
| Package Weight | 10.3 lb |
| Box Dimensions (LxWxH) | 17.3 x 11 x 8.1" |
| Others | |
| Marka | Blackmagic Design |
