| General | |
|---|---|
| Number of Bays | 5x 3.5" SATA III (Hot-Swap) |
| Inputs/Outputs | 2x RJ45 10GbE 3x RJ45 Gigabit Ethernet 1x VGA 2x USB-A 3.0 / 3.1/3.2 Gen 1 2x USB-A 2.0 |
| Media Card Slots | No |
| PCI Expansion | Full-Height,Half-Length 1x PCIe 3.0 x16 |
| Packaging Info | |
| Package Weight | 28.505 lb |
| Box Dimensions (LxWxH) | 20.3 x 17.6 x 15.4" |
| Physical | |
| Dimensions | 12.8 x 8.9 x 8.7" / 32.5 x 22.6 x 22.1 cm |
| Weight | 35.0 lb / 15.9 kg |
| Operating Conditions | 32 to 122°F / 0 to 50°C at 5 to 90% Humidity |
| Cooling | 1x Fan |
| Drives | |
| Storage Capacity | 80 TB |
| RAID | Yes: Supported RAID Modes: Z0 / Z1 / Z2 / Z3 / ZFS Mirror (Preconfigured in RAID Z1) |
| Included Drives | 5x 16 TB SATA III 3.5" HDD (512 MB Cache) 7200 RPM |
| Computing | |
| CPU | Quad-Core: Up to GHz |
| Processor | Intel Xeon D-1518 |
| Memory | 32 GB ECC 2666 MT/s DDR4 |
| RAM Configuration / Capacity | User-Replaceable 32 GB / Supporting up to 64 GB |
| Software | |
| OS Compatibility | macOS Windows 11 Windows 10 (32-/64-Bit) Windows Server 2003 Windows Server 2003 R2 Windows Server 2008 Windows Server 2008 R2 Windows Server 2012 Windows Server 2012 R2 Windows Server 2016 Windows Server 2019 Windows Server 2022 Chrome OS Linux FreeBSD |
| Installed Operating System | No |
| Mobile App Compatible | No |
| Security | |
| Encryption | Yes, 256-Bit AES |
| Security Features | Lockable Bay Door |
| VPN Connections | No |
| Networking | |
| Link Aggregation and Failover Support | Yes |
| iSCSI Support | Yes |
| Others | |
| Marka | OWC |
