| General | |
|---|---|
| Weight | 7.72 lb / 3.50 kg (Body Only) |
| Dimensions (W x H x D) | 14.75 x 8.75 x 7.75" / 37.47 x 22.23 x 19.68 cm |
| Accessory Mounting Thread | 4x 1/4"-20 1x ARRI/Hirth Rosette |
| Packaging Info | |
| Package Weight | 8.25 lb |
| Box Dimensions (LxWxH) | 14.9 x 8.8 x 8" |
| Imaging | |
| Lens Mount | ARRI PL |
| Image Sensor | 27.03 x 14.25 mm (Super35) CMOS |
| Effective Sensor Resolution | 79.6 Megapixel (12,288 x 6480) |
| Lens Communication | Yes |
| Image Stabilization | No |
| Built-In ND Filter | Mechanical Filter Wheel with Clear, 2-Stop (1/4), 4-Stop (1/16), 6-Stop (1/64) ND Filters |
| Capture Type | Stills & Video |
| Internal Filter Holder | No |
| Video Capture | |
| Internal Recording | 12288 x 6480 up to 60.00 fps 11520 x 6480 7680 x 6408 12288 x 5112 up to 75 fps 7680 x 4320 5120 x 4272 8192 x 3408 up to 120 fps 8192 x 3408 up to 160 fps 6144 x 3240 up to 120 fps* 4096 x 2160p up to 240 fps* 4096 x 2160p up to 120 fps 3840 x 2160p 2560 x 2136 4096 x 1704 up to 160 fps *Sensor Crops During Recording |
| Video Output | 4096 x 2160p up to 60.00 fps 1920 x 1080p 1920 x 1080i 1280 x 720 720 x 576p 720 x 576i 640 x 480p 640 x 480i |
| Fast-/Slow-Motion Support | Yes |
| Built-In Microphone | Stereo |
| IP Streaming | No |
| Exposure Control | |
| Shutter Type | Electronic Rolling Shutter |
| Advertised Dynamic Range | 14 Stops |
| Interface | |
| Media/Memory Card Slot | Dual Slot: SD/SDHC/SDXC (UHS-II) Dual Slot: CFast (CFast 2.0) |
| Internal Storage | No |
| Video I/O | 1x BNC (12G-SDI) Input 1x BNC (12G-SDI) Output 1x BNC (3G-SDI) Output |
| Audio I/O | 2x XLR 3-Pin Mic/Line Output (+48 V Phantom Power) 1x 1/8" / 3.5 mm TRRS Headphone/Mic Input/Output |
| Power I/O | 1x XLR 4-Pin Input 1x Molex 12-Pin Input/Output 1x XLR 4-Pin (12VDC) Output |
| Other I/O | 1x USB-C (USB 3.2 / 3.1 Gen 2) 1x USB-C Data Input |
| Wireless | Bluetooth LE |
| Mobile App Compatible | Yes: iOS & iPadOS |
| Global Positioning (GPS, GLONASS, etc.) | No |
| Viewfinder | |
| Type | Optional, Not Included |
| Others | |
| Marka | Blackmagic Design |
