| General | |
|---|---|
| Number of Bays | 8x 2.5"/3.5" SATA III |
| Inputs/Outputs | 2x USB-C Thunderbolt 3 (40 Gb/s) |
| Media Card Slots | No |
| PCI Expansion | No |
| Packaging Info | |
| Package Weight | 34.935 lb |
| Box Dimensions (LxWxH) | 18 x 17.9 x 17.7" |
| Physical | |
| Dimensions | 10.2 x 9.4 x 7.1" / 25.9 x 23.9 x 18 cm |
| Weight | 27.9 lb / 12.7 kg |
| Material of Construction | Aluminum |
| Operating Conditions | 41 to 95°F / 5 to 35°C at 8 to 90% Humidity |
| Certifications | BSMI, CE, FCC, RCM, VCCI |
| Storage Conditions | -4 to 140°F / -20 to 60°C at 5 to 95% Humidity |
| Cooling | 1x 92 mm Fan |
| Drives | |
| Storage Capacity | 96 TB |
| RAID | Yes: Supported RAID Modes: 0 / 1 / 4 / 5 / 10 / JBOD (Preconfigured in RAID 5) |
| Included Drives | 8x 12 TB SATA III 3.5" HDD 7200 RPM |
| Transfer Rates | 2586 MB/s (RAID Mode Unspecified) 1442 MB/s (Read in RAID 0) 1736 MB/s (Write in RAID 0) |
| Computing | |
| Bridge Chipset | Intel JHL-6540 JMicron JMB-585 |
| Electrical | |
| PSU | 1 x 300 W |
| Input Power | 12 VDC at 25 A 90 to 264 VAC, 60 / 50 Hz at 1.8 to 3.5 A |
| Software | |
| OS Compatibility | Windows 10 (64-Bit Only) Windows 11 Windows Server 2022 macOS 10.14 to 15 |
| Security | |
| Encryption | No |
| Security Features | Kensington Security Slot, Lockable Bay Door |
| Others | |
| Marka | OWC |
