| Connectivity | |
|---|---|
| Mobile App Compatible | Yes: Android & iOS App Name: SURUI Master |
| Inputs/Outputs | 1x USB-A1 A 5 VDC 1x USB-C1 A 5 VDC 1x Barrel2 A 8 VDC 1x Barrel2 A 16.8 VDC |
| Wireless Range | 98.4' / 30 m |
| General | |
| Dimensions | 19.1 x 8 x 7.3" / 486 x 202 x 185 mm |
| Weight | 3.22 lb / 1.46 kg 4.06 lb / 1.84 kg (with Battery) |
| Operating Conditions | -4 to 113°F / -20 to 45°C |
| Display Type | Fixed Non-Touchscreen OLED |
| Gimbal Design | Single Handgrip (Slanted) |
| Accessory Mounting | 1 x 1/4"-20 Female |
| Packaging Info | |
| Package Weight | 6.285 lb |
| Box Dimensions (LxWxH) | 16.4 x 9.8 x 3.8" |
| Compatibility | |
| Camera Control | On Compatible Models (See Full Compatibility List) |
| Battery | |
| Battery Type | 1x 18650 |
| Battery Runtime | 10 Hours |
| Battery Charging Time | 1.5 Hours |
| Gimbal | |
| Number of Axes | Three: Pitch (Tilt) / Roll / Yaw (Pan) |
| Rotation Range | Controllable Range Roll: 60° (-30 to 30°)  Pitch (Tilt): 270° (-90 to 180°)  Yaw (Pan): 360° Unlimited  Mechanical Range Roll: 320° (-90 to 230°)  Pitch (Tilt): 320° (-115 to 205°)  Yaw (Pan): 360° Unlimited  |
| Load Capacity | 7.7 lb / 3.5 kg |
| Follow Speed | Pan: 120°/s Tilt: 120°/s Roll: 120°/s |
| Others | |
| Marka | Sirui |
