| General | |
|---|---|
| Certifications | CE, FCC, Kcc |
| Dimensions | 5.28 x 3.63 x 0.9" / 13.41 x 9.22 x 2.29 cm |
| Weight | 8.1 oz / 230 g |
| Operating Conditions | 32 to 72°F / 0 to 22°C |
| Storage Conditions | -4 to 140°F / -20 to 60°C |
| Packaging Info | |
| Package Weight | 1.07 lb |
| Box Dimensions (LxWxH) | 5.8 x 5.5 x 2.7" |
| Power | |
| Power Consumption | Device: 6 W |
| Power I/O | 1x Barrel (6 to 30 VDC ) Input |
| Inputs/Outputs | |
| Video I/O | Output 2x BNC (3G-SDI) 1x HDMI 1.4 |
| Other I/O | Input/Output 1x RJ45 2x BNC (Reference) |
| Expansion Slots | No |
| Format Support | |
| Video Resolution | HDMI Output 1920 x 1080p at 23.98/24/25/29.97/30/50/59.94/60 fps 1920 x 1080i at 50/59.94/60 fps SDI Output (10-Bit 4:2:2 YUV) 1920 x 1080p at 23.98/24/25/29.97/30/50/59.94/60 fps 1920 x 1080i at 50/59.94/60 fps |
| Reclocking | No |
| Standards | |
| HDR Support | No |
| Broadcast System Compatibility | NTSC |
| Video Standard Compliance | SMPTE: 259M/292M/296M/424M-B/425M-A/425M-B |
| IP Streaming | |
| IP Video | Decoding via H.264 1920 x 1080 |
| Others | |
| Marka | Blackmagic Design |
Price:
18.559,86 ₺
