| Display | |
|---|---|
| Display Size | 5" |
| Connectivity | |
| HDCP Support | No |
| Other I/O | 1x BNC Blackburst, Reference, Tri-Level Sync Input 1x RJ45 Control 1x RJ12 Control 1x RJ45 Talkback Input/Output 1x XLR 5-Pin Talkback Input/Output |
| Video Standard Compliance | SMPTE 292M/296M/424M/425M-A/425M-B |
| General | |
| Dimensions | 19 x 9.1 x 3.48" / 48.3 x 23.1 x 8.84 cm |
| Weight | 11.53 lb / 5.23 kg |
| Operating Conditions | 32 to 72°F / 0 to 40°C up to 90% Humidity |
| Storage Conditions | -4 to 140°F / -20 to 60°C |
| Rack Form Factor | 2 U |
| Packaging Info | |
| Package Weight | 12.695 lb |
| Box Dimensions (LxWxH) | 21.2 x 10.5 x 5.2" |
| Power | |
| Power Consumption | Device: 147 W |
| Power I/O | 2x IEC C14 Input |
| IP Encoding/Decoding | |
| IP Video | 1280 x 720 to 1920 x 1080 Encoding |
| Processing | |
| Switching Type | Pushbutton, Software |
| Color Processing | 10-Bit 4:2:2 |
| Latency | 10 Lines |
| Mix Effects | |
| Available M/E Layers | 4 M/E |
| Effect Types | 16x Chroma Key 21x Luma Key 4x Stinger 12x DVE |
| Downstream Keys | 4x Chroma, Luma, DVE |
| Generators | 2x Color 21x Pattern |
| Audio Mixing | 156-Channel Mixing |
| Hardware | |
| OS Compatibility | macOS 11.1 or Later / Windows 10 or Later |
| Wireless | No |
| Processor | Not Specified by Manufacturer |
| Input | |
| Video Inputs | 40x BNC (3G-SDI) |
| Number of Video Input Sources | 40 |
| Input Video Format | SDI (10-Bit 4:2:2) 1080p at 23.98/24/25/29.97/30/50/59.94/60 fps 1080i at 50/59.94/60 fps 720p at 50/59.94/60 fps |
| Embedded Audio Input | SDI: 2-Channel (per Input) |
| Audio Inputs | 2x 1/4" TRS Stereo Analog Female 1x BNC Stereo MADI |
| Input Audio Format | Analog |
| Output | |
| Video Outputs | 24x BNC (3G-SDI) 1x USB-C (USB Video) (Program) |
| Video Output Channels | 24 |
| Output Video Format | SDI (10-Bit 4:2:2) 1080p at 23.98/24/25/29.97/30/50/60 fps 1080i 50/59.94/60 fps 720p 50/59.94/60 fps |
| Embedded Audio Output | SDI USB-C |
| Audio Outputs | 2x 1/4" TRS 2x BNC Stereo MADI |
| Multiview Output | 16-Way Multiview via SDI |
| Output Audio Format | Analog |
| Others | |
| Marka | Blackmagic Design |
