| Display | |
|---|---|
| Screen Resolution | 1366 x 768 |
| Connectivity | |
| HDCP Support | Yes |
| Other I/O | 1x BNC Genlock Input 1x RJ45 Control 1x RJ45 1x USB-B |
| Video Standard Compliance | SMPTE 292M/296M/424M-B/425M-A/425M-B/ST-2081-1/ST-2081-10/ST-2082-1/ST-2082-10 |
| General | |
| Dimensions | 19 x 13.23 x 3.54" / 48.26 x 33.6 x 8.99 cm |
| Weight | 18.5 lb / 8.39 kg |
| Operating Conditions | 32 to 104°F / 0 to 40°C up to 90% Humidity |
| Storage Conditions | -4 to 140°F / -20 to 60°C |
| Rack Form Factor | 2 U |
| Packaging Info | |
| Package Weight | 21.95 lb |
| Box Dimensions (LxWxH) | 20.4 x 16.8 x 7" |
| Power | |
| Power Consumption | Device: 100 to 240 VAC (300 W) |
| Power I/O | 2x IEC C14 Input |
| Processing | |
| Switching Type | Pushbutton |
| Processing Resolution | DCI 4K |
| Color Processing | 10-Bit 4:2:2 YUV |
| Mix Effects | |
| Available M/E Layers | 4 M/E |
| Effect Types | 4x DVE 4x Chroma Key (8K) |
| Downstream Keys | 2x Chroma (8K) 4x Chroma (UHD) |
| Generators | 9x Pattern 2x Color |
| Hardware | |
| OS Compatibility | macOS 10.13 or Later / Windows |
| Wireless | Bluetooth / Wi-Fi |
| Input | |
| Video Inputs | 40x BNC (12G-SDI) |
| Input Video Format | SDI (10-Bit 4:2:2) 8K at 23.98/24/25/29.97/50/59.94 fps UHD 4K 23.98/24/25/29.97/50/59.94 fps 1080p 25/29.97/50/59.94 fps 1080i 50/59.94 fps 720p 50/59.94 fps |
| Audio Inputs | 2x 1/4" TRS Mono Analog Female |
| Output | |
| Video Outputs | 24x BNC (12G-SDI) |
| Output Video Format | SDI (10-Bit 4:2:2) 8K at 23.98/24/25/29.97/50/59.94 fps UHD 4K 23.98/24/25/29.97/50/59.94 fps 1080p 23.98/24/25/29.97/50/59.94 fps 1080i 50/59.94 fps 720p 50/59.94 fps |
| Audio Outputs | 2x 1/4" Balanced TS Mono Analog Female |
| Multiview Output | Yes |
| Others | |
| Marka | Blackmagic Design |
Price:
831.537,02 ₺
