| General | |
|---|---|
| Dimensions | 1.7 x 18.9" (44 x 482 mm) 1 RU size with built-in rackmount ears |
| Weight | 4 lb (1.81 kg) |
| OS Compatibility | Mac OS X 10.7 Lion and later OS X 10.8 Mountain Lion and later Windows Windows 7 Windows 8 |
| Temperature | Operating 32 to 104°F (0 to 40°C) Storage -4 to 113°F (-20 to 45°C) |
| Computer Interface | 1 x mini-B type USB 2.0 connector for initial setup, firmware updates and Converter Utility software control |
| Power Requirements | 110 - 220 VAC, 50/60 Hz 12 - 31 VDC redundant input Note: IEC power cord is required/not included, redundant power supply not included |
| Packaging Info | |
| Package Weight | 4.795 lb |
| Box Dimensions (LxWxH) | 19.35 x 7.65 x 3.45" |
| Standards | |
| Format Support | 4K DCI 4096 x 2160p: 60/50/30/29.97/25/24/23.98 UHD 3840 x 2160p: 60/59.94/50/30/29.97/25/24/23.98 2K 2048 x 1080p: 25/24/23.98 2048 x 1080PsF: 25/24/23.98 HD 1080p: 60/59.94/50/30/29.97/25/24/23.98 1080PsF: 60/59.94/50/30/29.97/25/24/23.98 1080i: 60/59.94/50 720p: 60/59.94/50 SD NTSC 525i: 59.94 PAL 625i: 50 |
| Video | |
| SDI Video Input | 4 x 10-bit SD/HD switchable camera inputs 1 x 10-bit SD/HD switchable program input from switcher, including Tally information embedded in the SDI signal |
| SDI Compliance | SMPTE 259M, SMPTE 292M |
| Video Sampling | 4:2:2 |
| Color Precision | 10-bit |
| Color Space | REC 601 REC 709 |
| Optical Fiber Video Input | 4 x single mode SD/HD switchable camera inputs with LC connector |
| Optical Fiber | Input 4 x single mode LC connectors for video with embedded audio Channels 1 & 2 are camera audio Channels 15 & 16 are talkback audio Output 4 x single mode LC connectors for video with embedded audio Channels 1 & 2 are camera audio Channels 15 & 16 are talkback audio |
| Audio | |
| Audio Sampling | 48 kHz 24-bit A/D conversion |
| Analog Audio Output | 4 x 3-Pin XLR Balanced Audio Pairs (1 x pair per fiber input) 2 x RCA jacks provide a L/R stereo pair |
| Talkback | 1 x 1/4" TRS headphone jack 1 x .206" TRS mic input for use with aviation style headset 1 x 3-pin XLR connector for talkback microphone 1 x Integrated speaker |
| Talkback Control | 8 x Front panel buttons for camera operator selection, lock, mute and un-mute |
| AES/EBU Talkback Loops | Input 1 x BNC mic input 1 x BNC headphone input Output 1 x BNC mic output 1 x BNC headphone output |
| Others | |
| Marka | Blackmagic Design |
