| General | |
|---|---|
| Dimensions | 19 x 1.75 x 5" / 48.3 x 4.4 x 12.7 cm |
| Weight | 4.4 lb / 2 kg |
| Power Input | 1 x IEC, 100-240 VAC, 50-60 Hz |
| Inputs | 2 x BNC, SD/HD/3G/6G/12G-SDI (inputs can be separate or unified for dual-link functionality) 1 x HDMI Type A, v2.0 1 x Optical fiber (optional) 1 x Stereo RCA, analog audio 2 x XLR, balanced analog audio, AES/EBU digital audio 1 x BNC, reference 1 x USB-C 1 x RJ45, Ethernet |
| Format Support | 3840 x 2160: 23.98/24/25/29.97/30/50/59.94/60 2048 x 1080p: 23.98/24 2048 x 1080PsF: 23.98/24 1080p: 23.98/24/25/29.97/30/50/59.94/60 1080PsF: 23.98/24/25/29.97/30 1080i: 50/59.94/60 720p: 50/59.94/60 NTSC PAL |
| Outputs | 2 x BNC, SD/HD/3G/6G/12G-SDI (outputs can be separate or unified for dual-link functionality) 4 x BNC, SD/HD/3G-SDI (quad-link 4K output or replicated SDI output option) 1 x HDMI Type A, v2.0 1 x Optical fiber (optional, not available with dual-link operation) 1 x BNC, reference output |
| Compatible Operating Systems | Mac OS X 10.10 or later Windows 8.1, 10 |
| SDI Compliance | SMPTE 259M, SMPTE 292M, SMPTE 296M, SMPTE 372M, SMPTE 425M |
| Audio Sampling | HD: 24-bit, 48 kHz SD: 20-bit, 48 kHz |
| Environmental | Operating Temperature: 41 to 122°F / 5 to 50°C Storage Temperature: -4 to 113°F / -20 to 45°C Relative Humidity: 0-90%, non-condensing |
| SDI Metadata Support | VITC/ATC support, SMPTE 12M. Video indexing support including WSS, RP186 and AFD, SMPTE 2016. Closed captioning support for conversions to and from 608 and 708, SMPTE 334M. |
| Video Sampling | 4:2:2 |
| Color Space | REC 601, REC 709 |
| Color Depth | 10-bit |
| Packaging Info | |
| Package Weight | 4.365 lb |
| Box Dimensions (LxWxH) | 19.4 x 5.6 x 3.1" |
| Others | |
| Marka | Blackmagic Design |
