| Connectivity | |
|---|---|
| Wireless | No |
| Analog Audio I/O | 4x XLR 3-Pin Balanced Mic Input (Front Panel) 2x 1/4" TRS Balanced/Unbalanced Line/Hi-Z Input (Front Panel) 2x 1/4" TRS Balanced Line Input (Front Panel) 4x 1/4" TRS Balanced Line Output 2x 1/4" TRS Unbalanced Headphone Output (Front Panel) |
| Phantom Power | 48 V, Selectable On/Off (Applied to All Inputs) |
| Digital Audio I/O | No |
| Host Connection / USB | 1x USB-C |
| Host Connection Protocol | USB 2.0 |
| USB (Non-Host) | No |
| Sync I/O | No |
| Network I/O | No |
| MIDI I/O | 1x DIN 5-Pin Input 1x DIN 5-Pin Output |
| Expansion Slots | No |
| General | |
| Display | No |
| Channels of I/O | Analog: 4 Inputs / 4 Outputs |
| Built-In DSP | No |
| Maximum Sampling Rate | 192 kHz / 24-Bit |
| Number of Microphone Inputs | 4 |
| Built-In Microphone | No |
| Input Level Adjustment | 4x Knob |
| Packaging Info | |
| Package Weight | 4.925 lb |
| Box Dimensions (LxWxH) | 12.9 x 8.1 x 4.6" |
| Physical | |
| Dimensions | 11.7 x 6.3 x 2.6" / 29.6 x 16 x 6.5 cm (Including Controls and Protrusions) |
| Weight | 3.5 lb / 1.6 kg |
| Operating Conditions | 41 to 95°F / 5 to 35°C |
| Power | |
| Power Consumption | 2.25 W |
| Power Requirements | AC/DC Power Adapter (Not Included) or USB Bus Power |
| AC/DC Power Adapter | 12 VDC, Center-Positive (Included) |
| Performance | |
| Frequency Response | Mic, Line Inputs: 20 Hz to 20 kHz +0/-0.4 dB (at 44.1/48 kHz, JEITA) 20 Hz to 40 kHz +0/-0.4 dB (at 88.2/96 kHz, JEITA) Line Outputs: 20 Hz to 20 kHz +0.2/-0.1 dB (at 44.1/48 kHz, JEITA) 20 Hz to 40 kHz +0.2/-0.4 dB (at 88.2/96 kHz, JEITA) |
| Maximum Input Level | Mic Inputs: +9 dBu Line Inputs: +20 dBu Hi-Z Inputs: +10 dBV |
| Headphone Output Power | 45 mW per Channel into 32 Ohms (0.1% THD) |
| Maximum Output Level | Line Outputs: +20 dBu |
| Impedance | Mic Inputs: 2.2 Kilohms Line Inputs: 10 Kilohms Line Outputs: 210 Ohms Hi-Z Inputs: ≥ 1 Megohm |
| SNR | Mic Inputs: 110 dB (A-Weighted, Min Gain) Line Inputs: 108 dB (A-Weighted, Min Gain) Line Outputs: 110 dB (A-Weighted, Max Gain) |
| THD+N | Mic Inputs: 0.0013% (1 kHz, Min Gain) Line Inputs: 0.0011% (1 kHz, Min Gain) Line Outputs: 0.0012% (1 kHz) |
| EIN | -128 dBu |
| Compatibility | |
| OS Compatibility | Computer: macOS 10.13 or Later / Windows 7 or Later Mobile: iOS Only |
| Mobile Device Compatibility | iPad iPhone |
| Processor Requirement | 2 GHz or Better |
| RAM Requirements | 2 GB |
| Required Hardware | Available USB 2.0 Port USB Cable (Included) |
| Signal Processing | |
| Pad | No |
| Gain/Trim Range | Mic/Line/Hi-Z Inputs: 56 dB |
| High-Pass Filter | No |
| Solo/Mute | No |
| Digital Audio | |
| Sample Rates | 44.1 to 192 kHz |
| Sample Rate Conversion | No |
| Bit Depths | 24-Bit |
| Sync Sources | Internal |
| Audio Storage & Playback | |
| Media/Memory Card Slot | No |
| Others | |
| Marka | Tascam |
