| Display | |
|---|---|
| Display Size | 5" |
| Connectivity | |
| HDCP Support | Yes |
| Other I/O | 1x RJ45 LAN 1x USB-C 1x BNC Reference Input 1x BNC Reference Output |
| Video Standard Compliance | SMPTE 259M/292M/296M/372M/424M/425M-A/425M-B/ST-2081-1/ST-2081-10/ST-2082-10 ITU -R BT.601/BT.656 |
| HDR Support | Yes |
| General | |
| Dimensions | 19 x 10.47 x 6.52" / 48.3 x 26.59 x 16.56 cm |
| Weight | 33 lb / 15 kg |
| Operating Conditions | 32 to 104°F / 0 to 40°C up to 90% Humidity |
| Storage Conditions | -4 to 140°F / -20 to 60°C |
| Rack Form Factor | 6 U |
| Packaging Info | |
| Package Weight | 40.975 lb |
| Box Dimensions (LxWxH) | 21.8 x 15.8 x 15.6" |
| Power | |
| Power Consumption | 140 W |
| Power I/O | 2x IEC C14 (100 to 240 VAC ) Input |
| Processing | |
| Switching Type | Pushbutton, Software |
| Processing Resolution | DCI 4K at 60 |
| Color Processing | 10-Bit 4:2:2 YUV 12-Bit 4:4:4 RGB |
| Audio Processing | 48 kHz / 24-Bit |
| Hardware | |
| OS Compatibility | macOS 13 or Later / Windows 10 or Later |
| Wireless | Bluetooth / Wi-Fi |
| Input | |
| Video Inputs | 120x BNC (12G-SDI) |
| Input Video Format | SDI (10/12-Bit 4:4:4/4:2:2 RGB, YUV) DCI 4K up to 60 fps UHD 4K up to 60 fps DCI 2K up to 60 fps DCI 2KPsF up to 30 fps 1080p up to 60 fps 1080PsF up to 30 fps 1080i up to 60 fps |
| Embedded Audio Input | SDI |
| Output | |
| Video Outputs | 80x BNC (12G-SDI) |
| Output Video Format | SDI (10/12-Bit 4:4:4 RGB, YUV) DCI 4K up to 30 fps UHD 4K up to 30 fps DCI 2K up to 60 fps DCI 2KPsF up to 30 fps 1080p up to 60 fps 1080PsF up to 30 fps 1080i up to 60 fps SDI (10-Bit 4:2:2 RGB, YUV) DCI 4K up to 60 fps UHD 4K up to 60 fps DCI 2K up to 60 fps DCI 2KPsF up to 30 fps 1080p up to 60 fps 1080PsF up to 30 fps 1080i up to 60 fps 720p at 50/59.94/60 fps 576i / 625 lines at 50 fps 480i / 525 lines at 59.94 fps |
| Embedded Audio Output | SDI |
| Others | |
| Marka | Blackmagic Design |
Price:
926.607,82 ₺
