| General | |
|---|---|
| Dimensions | Transmitter/Receiver: 5.1 x 3.7 x 1.3" / 130 x 95 x 32 mm (Excluding Antenna) |
| Weight | Transmitter: 11.4 oz / 322.00 g, Excluding Antenna Receiver: 11.3 oz / 320.00 g, Excluding Antenna |
| Operating Conditions | 14 to 104°F / -10 to 40°C |
| Environmental Resistance | No |
| Status Display | On Transmitter & Receiver |
| Packaging Info | |
| Package Weight | 2.82 lb |
| Box Dimensions (LxWxH) | 10.1 x 6.8 x 2.3" |
| Power | |
| Input Power | 7.4 to 16.8 VDC |
| Battery | Receiver/Transmitter: 1x L-Series Mount on Fixed Plate |
| Inputs/Outputs | |
| Video I/O | Transmitter: 1x HDMI 2.0 Input Transmitter: 1x HDMI 2.0 Output Transmitter: 1x BNC (3G-SDI) Input Transmitter: 1x USB-C (Unspecified Signal) Output Receiver: 1x HDMI 2.0 Output Receiver: 1x BNC (3G-SDI) Output |
| Audio I/O | No |
| Embedded Audio | HDMI/SDI |
| Power I/O | Transmitter/Receiver: 1x Barrel Input |
| Format Support | |
| Video Format | HDMI UHD 4K: 60/50/30/25/24 1080p: 60/50/30/25/24 1080i: 60/59.94/50 SDI 1080p: 60/50/30/25/24 1080i: 60/59.94/50 |
| Audio Format | Not Specified by Manufacturer |
| Timecode Support | No |
| Wireless | |
| Wi-Fi | Wi-Fi 6 (802.11ax); Tri-Band (2.4 & 5 + 5 GHz) |
| Bluetooth | No |
| Mobile App Compatible | Yes: Android & iOS App Name: Accsoon SEE |
| Wireless Range | 1.6 Miles / 2.5 km (Line-of-Sight) |
| # of Channels | 20 |
| Frequency Range | 2412 to 2472 MHz 5180 to 5580 MHz 5660 to 5825 MHz |
| Latency | 35 ms |
| RF Power | 17 dBm |
| Cellular Support | No |
| Mounting | |
| Tripod/Accessory Mounting | Receiver/Transmitter, Bottom 1x 1/4"-20 Female |
| Others | |
| Marka | Accsoon |
